Tsubaki

Clevis Connector, Leaf

product price: $10.49
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Industry Chain Size BL834
  • Chain Link Material Carbon Steel
  • Industry Chain Pitch 1 in
  • Chain Link Overall Width 1.281 in
  • Material Carbon Steel
See all product information

Product Information

Dimensions

Industry Chain Size BL834
Chain Link Overall Width 1.281 in
Hole Dia. (In.) 0.3768
Roller Link Plate Height (In.) 0.156
Outside Pin Dia. (In.) 0.375
Hole Dia. 0.3768 in
Overall Width (In.) 1.281
ANSI Chain Size BL834
Chain Pin Dia. 0.375 in
Inside Pin Dia. 0.375"
Pin Length (In.) 1.281
Length (In.) 1.000
Pin Length 1.281 in
Chain Overall Width 1.281 in
Pin Outside Diameter 0.375 in

Details

Chain Link Material Carbon Steel
Industry Chain Pitch 1 in
Material Carbon Steel
Pin Link Plate Thickness 0.156 in
Lubrication SAE 10 to SAE 50
Pin Link Plate Thickness (In.) 0.156
Temp. Range 15 Degrees to 300 Degrees F
Item Clevis Connector
Tensile Strength (Lb.) 34,800
Tensile Strength 34,800 lb/in
Clevis Connector Item Leaf Chain Clevis Connector
Chain Lacing 3 x 4
Pin Type Riveted
Pitch 1 in
Agency Compliance American National Standards Institute (ANSI)
Type Leaf Chain
Lacing 3 x 4
Maximum Operating Temperature 300 Degrees F
Standards ANSI
Chain Number BL834
Minimum Operating Temperature 15 Degrees F

Description

Clevis Connector, Chain Number BL834, Chain Overall Width 1.281 in, Lacing 3 x 4, Material Carbon Steel, Pin Outside Diameter 0.375 in, Pitch 1 in, Lubrication SAE 10 to SAE 50, Maximum Operating Temperature 300 Degrees F, Minimum Operating Temperature 15 Degrees F, Standards ANSI, Tensile Strength 34,800 lb/in
