Clevis Connector, Leaf

TSUBAKI| Zoro #: G1336264| Mfr #: BL844CL

$14.00 /ea

Orders over $50.00 ship free. DetailsStandard ground shipping

Technical Specifications

Zoro #: G1336264 Mfr #: BL844CL
Pin Type: RivetedLubrication: SAE 10 to SAE 50
Type: Leaf ChainPin Length (In.): 1.453
Temp. Range: 15 to 300FAgency Compliance: American National Standards Institute (ANSI)
Item: Clevis ConnectorANSI Chain Size: BL844
Lacing: 4 x 4Overall Width (In.): 1.453
Pin Link Plate Thickness (In.): 0.156Hole Dia. (In.): 0.3768
Roller Link Plate Height (In.): 0.156Length (In.): 1.000
Tensile Strength (Lb.): 46, 200Material: Carbon Steel
Pitch: 1"Pin Length (mm): -
Outside Pin Dia. (In.): 0.375Inside Pin Dia.: 0.375"
Country of Origin (subject to change): Japan

Product Description

Clevis Connector, Leaf Chain, ANSI Chain Size BL844, Pitch 1 In., Roller Link Plate Height (In.) 0.156, Hole Dia. (In.) 0.3768, Pin Length (In.) 1.453, Pin Length (mm) -, Inside Pin Dia. 0.375 In., Outside Pin Dia. (In.) 0.375, Pin Link Plate Thickness (In.) 0.156, Riveted Pin Type, 4 x 4 Lacing, Length (In.) 1.000, Overall Width (In.) 1.453, Tensile Strength (Lb.) 46, 200, SAE 10 to SAE 50, Carbon Steel Material, 15 to 300F, American National Standards Institute (ANSI)
