Shop TSUBAKI

Connecting Roller Link, Double Pitch

  • Mfr # C2080HASK1CL

  • Zoro # G2530902

product price:
$
67.99
/ea

Key Features

Roller Chain Link Item
Attachment Link
Roller Chain Link Type
K-1 Heavy Conveyor
Industry Chain Size
C2080H
Chain Link Material
600 Stainless Steel
Industry Chain Pitch
2 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
C2080HASK1CL
Zoro #
G2530902
UPC #
-
Country of Origin
Japan

Dimensions

Industry Chain Size
C2080H
Chain Link Overall Width
1.543 in
Chain Roller Dia.
0.625 in
Length (In.)
2.000
Overall Width (In.)
1.543
Width Between Roller Link Plates (In.)
0.625
Roller Link Plate Height
0.906 in
Roller Dia. (In.)
0.625
Inside Pin Dia.
0.312 in
Outside Pin Dia.
0.312 in
Pin Length
1.543 in
Width Between Roller Link Plates
0.625 in
Outside Pin Dia. (In.)
0.312
Roller Link Plate Height (In.)
0.906
Pin Link Plate Thickness (In.)
0.906
Pin Link Plate Thickness
0.906 in
Pin Length (In.)
1.543
ANSI Chain Size
C2080HAS
Chain Overall Width
1.543 in
Roller Diameter
5/8 in
Plate Height
0.906 in
Extended Pin Diameter
0.312 in
Plate Thickness
0.625 in

Details

Roller Chain Link Item
Attachment Link
Roller Chain Link Type
K-1 Heavy Conveyor
Chain Link Material
600 Stainless Steel
Industry Chain Pitch
2 in
Number of Strands
Single
Temp. Range
-40 Degrees to 750 Degrees F
Agency Compliance
American National Standards Institute (ANSI)
Item
Attachment Link
Max. Allowable Load (Lb.)
2400
Tensile Strength
15,400 lb/in
Pin Type
Cottered
Max. Allowable Load
2,400 lb
Rivet End to Center Line (In.)
0.720
Connecting End to Center Line
0.823 in
Tensile Strength (Lb.)
15,400
Pitch
2 in
Type
K-1 Attachment
Lubrication
SAE 10 to SAE 50
Connecting End to Center Line (In.)
0.823
Rivet End to Center Line
0.72 in
Material
Stainless Steel
Finish
Plain
Standards
ANSI
Link Type
Attachment
Number of Tab Holes
1
Material Grade
600
Minimum Operating Temperature
-40 Degrees F
Attachment Number
K-1
Centerline to Hole Center
0.72 in
Chain Number
C2080H
Centerline to Attachment End
0.823 in
Maximum Operating Temperature
750 Degrees F
Pin Contruction
Cottered Pin
Attachment Type
Tab

Description

Attachment Link, Attachment Number K-1, Attachment Type Tab, Material Stainless Steel, Chain Overall Width 1.543 in, Chain Number C2080H, Roller Diameter 5/8 in, Finish Plain, Pitch 2 in, Link Type Attachment, Centerline to Attachment End 0.823 in, Centerline to Hole Center 0.72 in, Extended Pin Diameter 0.312 in, Lubrication SAE 10 to SAE 50, Material Grade 600, Maximum Operating Temperature 750 Degrees F, Minimum Operating Temperature -40 Degrees F, Number of Tab Holes 1
