  6. Indexable Cutting Head Unit, SH16 SCLCL3, 0.7870 in L, Steel, 80 Degrees Diamond Insert Shape
Ultra-Dex Usa Indexable Cutting Head Unit, SH16 SCLCL3, 0.7870 in L, Steel, 80 Degrees Diamond Insert Shape 912-000-205 - main

Indexable Cutting Head Unit, SH16 SCLCL3, 0.7870 in L, Steel, 80 Degrees Diamond Insert Shape

  • Mfr # 912-000-205

  • Zoro # G9226016

product price:  $272.99
/ea
Free Shipping & Returns

Key Features

Overall Length
0.7870 in
Shank Material
Steel
Insert Shape
80 Degrees Diamond
ANSI Code
SH16 SCLCL3
ANSI Number
SH16 SCLCL3
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
912-000-205
Zoro #
G9226016
UPC #
-
Country of Origin
United States

Dimensions

Overall Length
0.7870 in
Bar Dia.
0.984"
Insert Thickness
0.1562"
Insert Size
32.52
Min. Bore Dia.
1.2600 in
Connection Size
25.00mm

Details

Item
Indexable Cutting Head Unit
Shank Material
Steel
Insert Shape
80 Degrees Diamond
ANSI Code
SH16 SCLCL3
ANSI Number
SH16 SCLCL3
Left/Right Hand
Left
Type
Turning
Inscribed Circle
3/4"
Mounting Style
Screw Lock
Rake
Positive
Min. Bore
1.260"
Style
Chatter-Free
Cutting Edge Type
-5 Degrees
For Use With
CCMT 32.52
Lead Angle
-5 Degrees
Cutting Direction
Left Hand
Cutting Application
Boring
Coolant Fed
Coolant Through
Insert Clearance Angle
7 Degrees
Hardware Required
Insert Screw MTS-35, Key T-15
Insert Holding Type
Screw On
Center to Cutting Tip
0.6690 in
Side Cutting Edge Angle
-5 Degrees
Toolholder Style
SCLC
Compatible Hardware
Insert Screw MTS-35, Key T-15
Insert Inscribed Circle
3/8 in
Number of Coolant Holes
1
Insert Style
CCMT

Description

Indexable Cutting Head Unit, SCLC, Left Hand, Center to Cutting Tip 0.6690 in
