  11. Threading Insert, Top Notch, NTP, 0.0030 in, Carbide
Ultra-Dex Usa Threading Insert, Top Notch, NTP, 0.0030 in, Carbide 913-000-331 - main

Threading Insert, Top Notch, NTP, 0.0030 in, Carbide

  • Mfr # 913-000-331

  • Zoro # G9239483

product price: $35.49
/ea
Sold in multiples of 10 for $354.90

Key Features

Insert Shape
Top Notch
Insert Style
NTP
Insert Size
2
Grade
UD51
Corner Radius
0.0030 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
913-000-331
Zoro #
G9239483
UPC #
-
Country of Origin
United States

Dimensions

Insert Size
2
Corner Radius
0.0030 in
Insert Thickness
0.219"
Cutting Height
0.2190 in
Insert Length
17/64 in

Details

Item
Threading Insert
Insert Shape
Top Notch
Insert Style
NTP
Grade
UD51
Insert Material
Carbide
ISO Number
NTP-2L
Hardened (H) Compatibility
No
Style
NTP
Coating
TiN
No. of Edges
1
Cutting Direction
Neutral
Cast Iron (K) Compatibility
No
Steel (P) Compatibility
Yes
Super Alloy (S) Compatibility
No
Stainless (M) Compatibility
Yes
Non Ferrous (N) Compatibility
No
Workpiece Compatibility
Stainless (M), Steel (P)
Mounting Style
Top Notch Clamp
For Use With
Mfr. No. NEL2
ANSI Number
NTP-2L
Insert Type
NTP
Hole Type
No Hole
Measurement System
Fractional Inch
Material - Machining
Carbide
Primary Material Application ISO Code
P
ANSI Code
NTP-2L
Finish - Machining
TiN
Secondary Material Application ISO Code
K, M, S
Secondary Material Application
Cast Iron, Nickel, Stainless Steel, Titanium
Clearance Angle
5 Degrees
Primary Material Application
Steel
Cutting Application
Threading
Number of Cutting Edges
1
Max. Thread Pitch
20
Thread Direction
Left Hand
Side-to-Cutting Tip
0.0750 in
Min. Thread per Inch
1
Product Family
Top Notch
Manufacturer Grade
UD51
Coating Process
CVD
Threading Location
Internal
Included Angle
60 Degrees
Insert Holding Type
Top Clamp

Description

Threading Insert, NTP, Internal, Cutting Direction Neutral, Product Family Top Notch, Primary Material Application Steel
