U.S. Motors Direct Drive Blower Motor M055AYZ3660015B - main

Direct Drive Blower Motor

  • Mfr # M055AYZ3660015B

  • Zoro # G3159584

product price: $416.99
/ea
Free Shipping & Returns

Key Features

HP
1/3, 3/4
Nameplate RPM
1,075
Voltage
115/208-230V AC
Frame
48Y
Shaft Dia.
1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
M055AYZ3660015B
Zoro #
G3159584
UPC #
786382132552
Country of Origin
Mexico

Dimensions

Shaft Dia.
1/2 in
Shaft Length
5 in
Body Dia.
5 5/8 in
Overall Length
11 1/8 in
Length Less Shaft
6 1/8 in

Details

HP
1/3, 3/4
Nameplate RPM
1,075
Voltage
115/208-230V AC
Frame
48Y
Motor Shaft Rotation
CW/CCW
RPM Range
1,001-1,100
Standards
CSA Certified, UL Recognized
Full Load Amps
9.3/5.9-5.5 A; 9.4/5.9-5.5 A
Motor Shaft Design
Flat
Number of Shafts
1
Motor Mounting Type
Band
Motor Sub Application
Direct Drive Fan/Blower
Item
Direct Drive Blower Motor
Motor Enclosure Design
Open Air-Over
Motor Application
Blower; Fan
Voltage Compatibility
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC, 208-230V AC, 208-240V AC, 208V AC, 230V AC, 240V AC
OEM Replacement Brand
Amana
Ins. Class
B
Duty
Continuous
No. of Speeds
1
Phase
Single
Motor Design
ECM
Capacitor Required
No
Motor Bearings
Ball
Motor Thermal Protection
Auto
Max. Ambient Temp.
40 Degrees C
Application
Fans and Blowers
Hz
60/50
Motor Service Factor
1
HP @ 50Hz
1/3, 3/4
Duty Cycle
Continuous
Usable @ 208V
Yes
Voltage @ 50Hz
115/208-230
Service Factor @ 50Hz
1
Full Load Amps @ 50Hz
9.3/5.9-5.5 A, 9.4/5.9-5.5 A
Usable @ 200V
No

Description

Fan and Blower Motor, Single Phase, Motor Design ECM, 1/3 hp, 3/4 hp HP, Nameplate RPM 1,075 RPM, No. of Speeds 1, Voltage 115/208-230V AC, 9.3/5.9-5.5 A; 9.4/5.9-5.5 A Full Load Amps, 48Y Frame, 60/50 Hz, Usable @ 208V Yes, Usable @ 200V No, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over, Motor Mounting Type Belly Band, Motor Frame Material Steel
