U.S. Motors GP Motor, 1-1/2 HP, 3505V RPM, 230/460 HD32P1EC - main

GP Motor, 1-1/2 HP, 3505V RPM, 230/460

  • Mfr # HD32P1EC

  • Zoro # G1932188

product price: $467.99
/ea
Free Shipping & Returns

Key Features

HP
1 1/2
Nameplate RPM
3,505
Voltage
230/460V AC
Frame
143TC
Shaft Dia.
7/8 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HD32P1EC
Zoro #
G1932188
UPC #
786382127299
Country of Origin
Mexico

Dimensions

Shaft Dia.
7/8 in
Shaft Length
2 1/8 in
Length Less Shaft
11 7/8 in
Overall Length
14 in
Manufacturers Warranty Length
3 yr

Details

HP
1 1/2
Nameplate RPM
3,505
Voltage
230/460V AC
Frame
143TC
Motor Shaft Rotation
CW/CCW
RPM Range
3,001-3,600
Motor Design
Three-Phase
Item
General Purpose Motor
Full Load Amps
3.9/1.9 A
Motor Application
General Purpose
Motor Shaft Design
Keyed
Max. Ambient Temp.
40 Degrees C
No. of Speeds
1
Motor Service Factor
1.15
Motor Sub Application
Foundries, Mines, Pulp and Paper Plants
Motor Enclosure Design
Totally Enclosed Fan Cooled
Ins. Class
F
Motor Thermal Protection
None
Motor Mounting Position
Horizontal
Hz
60/50 Hz
Phase
Three
Motor Mounting Type
Rigid Base
Motor Bearings
Ball
Voltage Compatibility
200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC
Nominal Efficiency
84 %
Usable @ 200V
Yes
NEMA Design
B
Standards
CSA Certified, UL Recognized
Bearing Protection
Double Shielded
Weight
50 lb
Motor Frame Material
Cast Iron
Usable @ 208V
Yes
Removable Base
Regreasable
HP @ 50Hz
1 1/2 hp
Voltage @ 50Hz
200/400V AC
Includes
All Cast Iron Upgrade, C&D Flanges, Canopy Kits
Inverter Rated
Yes
Duty Cycle
Continuous
Service Factor @ 50Hz
1.15
RPM @ 50Hz
2,890
Part Winding Start Capable
No
Full Load Amps @ 50Hz
4.4/2.2 A
Inverter Rating
20:1 (3-60hz) Variable Torque, 5:1 (12-60hz) Constant Torque

Description

General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 1 1/2 HP, Nameplate RPM 3,505, Frame 143TC, Voltage 230/460V AC, 60/50 Hz Hz, Three Phase, Full Load Amps 3.9/1.9 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 84 Percent, 3,001-3,600, CSA Certified, UL Recognized
