U.S. Motors GP Motor, 2 HP, 3510V RPM, 230/460,145TC HD2P1EC - main

GP Motor, 2 HP, 3510V RPM, 230/460,145TC

  • Mfr # HD2P1EC

  • Zoro # G1932702

product price: $497.99
/ea
Free Shipping & Returns

Key Features

HP
2
Nameplate RPM
3,510
Voltage
230/460V AC
Frame
145TC
Shaft Dia.
7/8 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
HD2P1EC
Zoro #
G1932702
UPC #
78638217251
Country of Origin
Mexico

Dimensions

Shaft Dia.
7/8 in
Shaft Length
2 1/8 in
Manufacturers Warranty Length
3 yr
Length Less Shaft
11 7/8 in
Overall Length
14 in

Details

HP
2
Nameplate RPM
3,510
Voltage
230/460V AC
Frame
145TC
Motor Shaft Rotation
CW/CCW
RPM Range
3,001-3,600
Max. Ambient Temp.
40 Degrees C
Motor Bearings
Ball
Full Load Amps
5/2.5 A
Phase
Three
Item
General Purpose Motor
Motor Application
General Purpose
Motor Sub Application
Foundries, Mines, Agricultural Fan
Motor Thermal Protection
None
Motor Shaft Design
Keyed
Motor Service Factor
1.15
Hz
60/50 Hz
Motor Mounting Position
Horizontal
Voltage Compatibility
200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC
Ins. Class
F
No. of Speeds
1
Motor Enclosure Design
Totally Enclosed Fan Cooled
Motor Design
Three-Phase
Motor Mounting Type
Rigid Base
Includes
All Cast Iron Upgrade, C&D Flanges, Canopy Kits
NEMA Design
B
Bearing Protection
Double Shielded
Nominal Efficiency
85.5 %
Usable @ 200V
Yes
Motor Frame Material
Cast Iron
Weight
50 lb
Standards
CSA Certified, UL Recognized
Usable @ 208V
Yes
Removable Base
Regreasable
Voltage @ 50Hz
200/400V AC
Service Factor @ 50Hz
1
Part Winding Start Capable
No
Inverter Rated
Yes
Duty Cycle
Continuous
Full Load Amps @ 50Hz
5.7/2.9 A
HP @ 50Hz
2 hp
RPM @ 50Hz
2,892
Inverter Rating
20:1 (3-60hz) Variable Torque, 5:1 (12-60hz) Constant Torque

Description

General Purpose Motor, Three-Phase, Totally Enclosed Fan Cooled Motor Enclosure Design, 2 HP, Nameplate RPM 3,510, Frame 145TC, Voltage 230/460V AC, 60/50 Hz Hz, Three Phase, Full Load Amps 5/2.5 A, Rigid Base Motor Mounting Type, Motor Thermal Protection None, Ins. Class F, Motor Service Factor 1.15, Ball Motor Bearings, Motor Frame Material Cast Iron, Max. Ambient Temp. 40 Degrees C, CW/CCW Motor Shaft Rotation, Nominal Efficiency 85.5 Percent, 3,001-3,600, CSA Certified, UL Recognized
