  6. Farm Duty Motor, Capacitor-Start, 1 1/2 HP, 115/230V AC, 3,450 Nameplate RPM, 143TZ Frame
U.S. Motors Farm Duty Motor, Capacitor-Start, 1 1/2 HP, 115/230V AC, 3,450 Nameplate RPM, 143TZ Frame FD32CA1P14 - main

Farm Duty Motor, Capacitor-Start, 1 1/2 HP, 115/230V AC, 3,450 Nameplate RPM, 143TZ Frame

  • Mfr # FD32CA1P14

  • Zoro # G0408062

product price:  $517.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Capacitor-Start
Phase
Single
HP
1 1/2
RPM Range
3450 RPM
Voltage
115/230V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
FD32CA1P14
Zoro #
G0408062
UPC #
786382025809
Country of Origin
Mexico

Dimensions

Overall Length
13 1/4 in
Length Less Shaft
11 in
Shaft Dia.
7/8 in
Shaft Length
2 1/4 in

Details

Item
Farm Duty Motor
Motor Design
Capacitor-Start
Phase
Single
HP
1 1/2
RPM Range
3450 RPM
Voltage
115/230V AC
Frame
143TZ
Motor Service Factor
1
Motor Thermal Protection
Auto
Motor Enclosure Design
Totally Enclosed Air-Over
Nameplate RPM
3,450
Motor Application
Aeration Fan Motor, Crop Dryer Motor
Motor Frame Material
Steel/Aluminum
Motor Mounting Type
Rigid Base
Motor Shaft Design
Keyed
Motor Sub Application
Aeration Fan; Crop Dryer
Motor Shaft Rotation
CCW
Full Load Amps
17.4/8.7 A
Hz
60 Hz
Motor Bearings
Ball
Capacitor Required
Yes
Item - Farm Duty Motors
General Purpose Farm Duty Motor
Nominal Efficiency
73 %
Duty
CONTINUOUS
Ins. Class
B
No. of Speeds
1
Max. Ambient Temp.
40 Degrees C

Description

Farm Duty Motor, Single Phase, Motor Design Capacitor-Start, 1 1/2 hp HP, Nameplate RPM 3,450 RPM, No. of Speeds 1, Voltage 115/230V AC, Full Load Amps 17.4/8.7 A, 143TZ Frame, Usable @ 208V Not Usable at 208V, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Rigid Base, Motor Frame Material Steel
