Shop U.S. MOTORS

Motor, 1/30HP, 1100/3SPD, 115-127V, 60HZ

  • Mfr # 4125

  • Zoro # G0915352

product price:  $208.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Permanent Split Capacitor
HP
1/3
RPM Range
1,101-1,200
Nameplate RPM
1,100
Voltage
115-127V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
4125
Zoro #
G0915352
UPC #
786382080655
Country of Origin
Mexico

Dimensions

Length Less Shaft
5 11/16 in
Overall Length
13 5/32 in
Shaft Length
8 in
Shaft Dia.
1/2 in
Body Dia.
5 in
Frame Size
42
Body Diameter
5 in
Shaft Diameter
1/2 in
Wire Rope Length
13 5/32 in

Details

Item
Fan and Blower Motor
Motor Design
Permanent Split Capacitor
HP
1/3
RPM Range
1,101-1,200
Nameplate RPM
1,100
Voltage
115-127V AC
Frame
42
Motor Mounting Type
Resilient Base
Phase
Single
Motor Enclosure Design
Open Air-Over
Hz
60 Hz
Ins. Class
B
Max. Ambient Temp.
40 Degrees C
Duty
Continuous
No. of Speeds
3
Motor Thermal Protection
Auto
Motor Shaft Rotation
CCWLE
Max. Amps
0.76 A
Motor Service Factor
0.53
Motor Bearings
Self Align (Opposite End Bearing); Self Align (Shaft End Bearing)
Full Load Amps
0.53 A
Weight
12.19 lb
Blower Stages
1
Duty Cycle
Continuous
Product Type
Fan and Blower Motor
Nameplate Service Factor @ 60 Hz
1
Number of Speeds
3
Frame Material
Steel
Capacitor Required
Capacitor Included
Sub Application
General Purpose
Full Load Current @ 60 Hz
0.53 A
Frequency
60 Hz
Motor Enclosure Type
Open Air Over
Insulation Class
B
Drive Type
Direct Drive
Ambient Temperature - Maximum
40 Degrees C
Number of Blower Stages
1

Description

Fan and Blower Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/30 hp HP, Nameplate RPM 1,100 RPM, No. of Speeds 3, Voltage 115-127V AC, 0.53 A Full Load Amps, 42 Frame, 60 Hz Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CCWLE, Motor Enclosure Design Open Air Over, Motor Mounting Type Cradle Base, Motor Frame Material Steel, Shaft Length 8 in, Shaft Dia. 1/2 in
