Shop U.S. MOTORS

Motor, 1/3HP, 825RPM, 208-230V, 60HZ, 48Y

  • Mfr # 6873

  • Zoro # G0916210

product price:  $267.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Permanent Split Capacitor
HP
1/3
RPM Range
0-1,000
Nameplate RPM
825
Voltage
208-230V AC
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
6873
Zoro #
G0916210
UPC #
786382006471
Country of Origin
Mexico

Dimensions

Shaft Dia.
1/2 in
Length Less Shaft
6 29/32 in
Overall Length
11 13/32 in
Body Dia.
5 5/8 in
Shaft Length
4 1/2 in
Shaft Diameter
1/2 in
Frame Size
48Y
Body Diameter
5.6 in
Wire Rope Length
11 13/32 in

Details

Item
Fan and Blower Motor
Motor Design
Permanent Split Capacitor
HP
1/3
RPM Range
0-1,000
Nameplate RPM
825
Voltage
208-230V AC
Frame
48
Motor Mounting Type
Hub
Phase
Single
Motor Enclosure Design
Open Air-Over
Ins. Class
B
Motor Bearings
Ball (Opposite End Bearing); Ball (Shaft End Bearing)
No. of Speeds
1
Max. Amps
5.07 A
Max. Ambient Temp.
40 Degrees C
Motor Thermal Protection
Auto
Motor Shaft Rotation
CW/CCW
Duty
Continuous
Hz
60 Hz
Full Load Amps
2.7 A
Watts
300 W
Weight
15.09 lb
Duty Cycle
Continuous
Drive Type
Direct Drive
Insulation Class
B
Sub Application
General Purpose
Frame Material
Steel
Wattage
300 W
Product Type
Fan and Blower Motor
Bearing Type
Ball
Ambient Temperature - Maximum
40 Degrees C
Motor Enclosure Type
Open Air Over
Capacitor Required
Capacitor Not Included
Frequency
60 Hz
Full Load Current @ 60 Hz
2.7 A
Number of Speeds
1

Description

Fan and Blower Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/3 hp HP, Nameplate RPM 825 RPM, No. of Speeds 1, Voltage 208-230V AC, 2.7 A Full Load Amps, 48Y Frame, Output Watts 300 W, 60 Hz Hz, Motor Thermal Protection Auto, Ins. Class B, Duty Cycle Continuous, Max. Ambient Temp. 40 Degrees C, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Air Over, Motor Mounting Type Hub, Motor Frame Material Steel, Shaft Length 4 1/2 in, Shaft Dia. 1/2 in
