  5. 230V 3000Va 3000W On Line 2U Rack-Mountable with LCD 8 x IEC AVR ECO SNMP NC

This item is Discontinued.

V7 230V 3000Va 3000W On Line 2U Rack-Mountable with LCD 8 x IEC AVR ECO SNMP NC UPS2URM3000DC-NC-1N

230V 3000Va 3000W On Line 2U Rack-Mountable with LCD 8 x IEC AVR ECO SNMP NC (Discontinued)

  • Mfr # UPS2URM3000DC-NC-1N
  • Zoro # G112177383
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
UPS2URM3000DC-NC-1N
Zoro #
G112177383
UPC #
662919114843
Country of Origin
China

Dimensions

Width
17.2 in
Height
3.4 in
Length
24.8 in
Rack Height
2U

Details

Item
Double Conversion Online UPS
Features
Overload Protection
Color
Black
Application
Edge Computing, Healthcare, Manufacturing, Finance, Industrial Automation System, Server Room, Network Closet, Retail
Phase
Single
Input Voltage
120V AC
Green Environmental Attribute
Energy Star; Environmentally Friendly
Mounting
Rack
Standards
TAA Compliant
Display Type
LCD
Output Voltage
120V AC, 100V AC, 127V AC, 110V AC, 115V AC
Voltage
82.1V DC
Includes
US NEMA 2.4m 5-15P Power Cable, 1.5m USB Cable, Mounting Rails, Tower Feet, User's Guide, Warranty & Compliance
Series
On-Line
Max. Operating Temperature
104°F
Load Capacity
3000 VA
Surge Energy Rating
720 J
Alarm
Fault, Battery Mode, Low Battery, Overload
EPO Port
Yes
Typical Battery Recharge Time
3 hrs
Receptacles
(6) NEMA 5-15/20R, (1) NEMA L5-30R
Sound Emission (A-Weighted)
50 dB(A)
Number of Batteries
6
Plug/Connector Type
NEMA L5-30P
Dataline Protection
RJ-11/RJ-45
Input Frequency
70 Hz
Output Power Factor
0.9
USB
Yes
Operating Humidity
20% to 95%
Run Time (Half Load/Full Load)
10 min/2.6 min
Network Management
SNMP, Smart RS-232/USB
Status Indicators
LCD Display: AC Mode, Battery Mode, Load Level, Battery Level, Input Voltage, Output Voltage, Overload, Fault, Low Battery
Battery Characteristics
Sealed
Battery Chemistry
Lead Acid
Battery Capacity
9000 mAh
Waveform Type
Pure Sine Wave
Output Frequency
60 Hz
Input Power Factor
0.99
