Butterfly Valve, Flanged, 6 In, Actuated, CI
Mfr # 2006-1B08AK
Zoro # G0701084
product price:Â $1,290.99
/ea
Free Shipping & Returns
Key Features
Style
Flanged
Body Material
Cast Iron ASTM A126
Pipe Size
6 in
Max. Water Pressure
150 psi
Handle Type
Gear Operated Handwheel
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
MFR #
2006-1B08AK
Zoro #
G0701084
UPC #
-
Country of Origin
United States
Dimensions
Pipe Size
6 in
Bolt Circle Dia.
3/4 in
Nominal Valve Size
6 in
Details
Item
Butterfly Valve
Style
Flanged
Body Material
Cast Iron ASTM A126
Max. Water Pressure
150 psi
Handle Type
Gear Operated Handwheel
Standards
AWWA C504, AWWA C516, NSF 372
Liner Material
Buna-N
Number of Bolt Holes
8
Temp. Range
-32 to 210 Degrees F
Disc Material
Ductile Iron
Operating Temperature - Minimum
-32 Degrees F
Coefficient of Volume (Cv)
1,430
Operating Temperature - Maximum
210 Degrees F
NSF Certifications for Food and Drinking Water
NSF 61
3-A Standard Compliance
Not Rated
For Media
Water
Number of Flange Bolt Holes
8
Connection Type
Lug
Maximum Pressure - Operating
150 psi
Vacuum Service Rating
Not Rated
Valve Series
2000
Description
Butterfly Valve, Flanged Style, Body Material Cast Iron ASTM A126, Max. Water Pressure 150 psi, Pipe Size 6 in, Temp. Range -32 to 210 Degrees F, Liner Material Buna-N, Disc Material Ductile Iron, Handle Type Gear Operated Handwheel, Number of Bolt Holes 8, Bolt Circle Dia. 3/4 in, Standards AWWA C504, AWWA C516, NSF 372
