  11. Male Disconnect, Blue, 16-14AWG, PK10
Velvac Male Disconnect, Blue, 16-14AWG, PK10 30387 - main

Male Disconnect, Blue, 16-14AWG, PK10

  • Mfr # 30387

  • Zoro # G5377477

product price: $9.39
/pk 10, $0.94/ea

Key Features

Insulation
Full
Insulation Color
Blue
Connection Type
Crimp
Insulation Type
Heat Shrink
Wire Range
16 to 14 AWG
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
30387
Zoro #
G5377477
UPC #
728974160741
Country of Origin
United States

Dimensions

Overall Length
1.35 in
Tab Size
0.032 in x 0.250 in
Barrel Inside Dia.
0.097 in
Minimum Wire Size
16 AWG
Barrel Inside Diameter
0.097 in
Tab Width
0.25 in
Maximum Wire Size
14 AWG
Tab Thickness
0.032 in

Details

Item
Male Disconnect
Insulation
Full
Insulation Color
Blue
Connection Type
Crimp
Insulation Type
Heat Shrink
Wire Range
16 to 14 AWG
Seam
Brazed
Max. Temp.
221 Degrees F
Max. Voltage
600 V
Connection Material
Copper
Standards
UL Listed
Minimum Operating Temperature
-40 Degrees F
Termination Style
Crimp
RoHS Compliant
Yes
Disconnect Style
Tab
Insulation Material
Nylon
Contact Material
Copper
Barrel Style
Funnel Entry
Seam Style
Brazed
Special Features
Crimp and Seal Style Terminals are the Most Comprehensive and Highest Quality Line of Crimp and Seal Heat Shrinkable Connectors in Todays Market, It Has Seamless Tubular Splices Which Ensure Mechanical and Electrical Integrity Under Severe Conditions, The Brazed Seam Terminals will Not Split Open Under the Most Extreme Installation and Operating Conditions, The Heat Shrink Tubing Which is 3:1 Dual Wall Tubing With Adhesive Lining Provides a Waterproof Seal With Durable Abrasion Resistance
Maximum Voltage
600 V
Insulation Coverage
Full Coverage
Maximum Operating Temperature
194 Degrees F
Terminal Type
Tab
Contact Finish
Tin

Description

Wire Disconnect, Contact Finish Tin, Contact Material Copper, Disconnect Style Quick Disconnect, Insulation Color Blue, Insulation Coverage Full Coverage, Insulation Material Nylon, Maximum Temperature 194 Degrees F, Minimum Wire Size 16 AWG, Maximum Wire Size 14 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Tab, Termination Style Crimp, RoHS Compliant Yes, Seam Style Brazed, Standards UL Listed, Barrel Inside Diameter 0.097 in, Barrel Style Funnel Entry
