  11. Male Disconnect, Red, 22-18AWG, PK10
Velvac Male Disconnect, Red, 22-18AWG, PK10 30197 - main

Male Disconnect, Red, 22-18AWG, PK10

  • Mfr # 30197

  • Zoro # G5377504

product price: $9.19
/pk 10, $0.92/ea

Key Features

Insulation
Full
Insulation Color
Red
Insulation Type
Heat Shrink
Wire Range
22 to 18 AWG
Connection Type
Crimp
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
30197
Zoro #
G5377504
UPC #
728974160727
Country of Origin
United States

Dimensions

Overall Length
1.35 in
Tab Size
0.032 in x 0.250 in
Barrel Inside Dia.
0.062 in
Tab Thickness
0.032 in
Minimum Wire Size
22 AWG
Tab Width
0.25 in
Barrel Inside Diameter
0.062 in
Maximum Wire Size
18 AWG

Details

Item
Male Disconnect
Insulation
Full
Insulation Color
Red
Insulation Type
Heat Shrink
Wire Range
22 to 18 AWG
Connection Type
Crimp
Seam
Brazed
Max. Voltage
600 V
Max. Temp.
221 Degrees F
Connection Material
Copper
Standards
UL Listed
RoHS Compliant
Yes
Barrel Style
Funnel Entry
Contact Finish
Tin
Insulation Coverage
Full Coverage
Insulation Material
Nylon
Seam Style
Brazed
Maximum Voltage
600 V
Disconnect Style
Tab
Special Features
Crimp and Seal Style Terminals are the Most Comprehensive and Highest Quality Line of Crimp and Seal Heat Shrinkable Connectors in Todays Market, It Has Seamless Tubular Splices Which Ensure Mechanical and Electrical Integrity Under Severe Conditions, The Brazed Seam Terminals will Not Split Open Under the Most Extreme Installation and Operating Conditions, The Heat Shrink Tubing Which is 3:1 Dual Wall Tubing With Adhesive Lining Provides a Waterproof Seal With Durable Abrasion Resistance
Termination Style
Crimp
Maximum Operating Temperature
194 Degrees F
Minimum Operating Temperature
-40 Degrees F
Contact Material
Copper
Terminal Type
Socket

Description

Wire Disconnect, Contact Finish Tin, Contact Material Copper, Disconnect Style Quick Disconnect, Insulation Color Red, Insulation Coverage Full Coverage, Insulation Material Nylon, Maximum Temperature 194 Degrees F, Minimum Wire Size 22 AWG, Maximum Wire Size 18 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Socket, Termination Style Crimp, RoHS Compliant Yes, Seam Style Brazed, Standards UL Listed, Barrel Inside Diameter 0.062 in, Barrel Style Funnel Entry
