  11. Male Disconnect, Red, 22-18AWG, PK10, Seam: Brazed
Velvac Male Disconnect, Red, 22-18AWG, PK10, Seam: Brazed 37187 - main

Male Disconnect, Red, 22-18AWG, PK10, Seam: Brazed

  • Mfr # 37187

  • Zoro # G5387067

product price: $7.82
/pk 10, $0.78/ea

Key Features

Insulation
Full
Insulation Color
Red
Wire Range
22 to 18 AWG
Insulation Type
Heat Shrink
Connection Type
Crimp
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
37187
Zoro #
G5387067
UPC #
728974160857
Country of Origin
United States

Dimensions

Overall Length
1.5 in
Tab Size
0.032 in x 0.250 in
Barrel Inside Dia.
0.062 in
Maximum Wire Size
18 AWG
Minimum Wire Size
22 AWG
Tab Thickness
0.032 in
Tab Width
0.25 in
Barrel Inside Diameter
0.062 in

Details

Item
Male Disconnect
Insulation
Full
Insulation Color
Red
Wire Range
22 to 18 AWG
Insulation Type
Heat Shrink
Connection Type
Crimp
Seam
Brazed
Max. Temp.
221 Degrees F
Max. Voltage
600 V
Connection Material
Copper
Standards
UL Listed
Disconnect Style
Tab
Insulation Material
Nylon/Polyolefin
Maximum Operating Temperature
221 Degrees F
Maximum Voltage
600 V
Termination Style
Crimp
RoHS Compliant
Yes
Insulation Coverage
Full Coverage
Contact Finish
Tin
Minimum Operating Temperature
-40 Degrees F
Contact Material
Copper
Barrel Style
Funnel Entry
Terminal Type
Tab
Special Features
Adhesive Lining Which Blocks Out Water, Adds Tensile Strength and Strain Relief, CNS Extreme Waterproof Wire Terminals are Designed to Perform in the Harshest Environments, It Has a Triple Layer of Protection Around a 99.9% Copper Connector for Maximum Strength and Conductivity, Polyolefin Shrink Tubing Which Allows a Complete Environment and An Abrasion Resistant Seal
Seam Style
Butted

Description

Wire Disconnect, Contact Finish Tin, Contact Material Copper, Disconnect Style Quick Disconnect, Insulation Color Red, Insulation Coverage Full Coverage, Insulation Material Nylon with Heat Shrink, Maximum Temperature 221 Degrees F, Minimum Wire Size 22 AWG, Maximum Wire Size 18 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Tab, Termination Style Crimp, RoHS Compliant Yes, Seam Style Butted, Standards UL Listed, Barrel Inside Diameter 0.062 in
