  11. Male Disconnect, Yellow, 12-10AWG, PK10
Velvac Male Disconnect, Yellow, 12-10AWG, PK10 30487 - main

Male Disconnect, Yellow, 12-10AWG, PK10

  • Mfr # 30487

  • Zoro # G5367625

product price: $11.19
/pk 10, $1.12/ea

Key Features

Insulation
Full
Insulation Color
Yellow
Connection Type
Crimp
Wire Range
12 to 10 AWG
Insulation Type
Heat Shrink
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
30487
Zoro #
G5367625
UPC #
728974161045
Country of Origin
United States

Dimensions

Tab Size
0.032 in x 0.250 in
Overall Length
1.75 in
Barrel Inside Dia.
0.142 in
Minimum Wire Size
12 AWG
Tab Thickness
0.032 in
Maximum Wire Size
10 AWG
Tab Width
0.25 in
Barrel Inside Diameter
0.142 in

Details

Item
Male Disconnect
Insulation
Full
Insulation Color
Yellow
Connection Type
Crimp
Wire Range
12 to 10 AWG
Insulation Type
Heat Shrink
Seam
Brazed
Max. Temp.
221 Degrees F
Max. Voltage
600 V
Connection Material
Copper
Standards
UL Listed
Maximum Operating Temperature
194 Degrees F
Contact Finish
Tin
Barrel Style
Funnel Entry
Special Features
Crimp and Seal Style Terminals are the Most Comprehensive and Highest Quality Line of Crimp and Seal Heat Shrinkable Connectors in Todays Market, It Has Seamless Tubular Splices Which Ensure Mechanical and Electrical Integrity Under Severe Conditions, The Brazed Seam Terminals will Not Split Open Under the Most Extreme Installation and Operating Conditions, The Heat Shrink Tubing Which is 3:1 Dual Wall Tubing With Adhesive Lining Provides a Waterproof Seal With Durable Abrasion Resistance
Disconnect Style
Tab
Insulation Coverage
Full Coverage
Insulation Material
Nylon
RoHS Compliant
Yes
Maximum Voltage
600 V
Minimum Operating Temperature
-40 Degrees F
Seam Style
Brazed
Contact Material
Copper
Terminal Type
Tab
Termination Style
Crimp

Description

Wire Disconnect, Contact Finish Tin, Contact Material Copper, Disconnect Style Quick Disconnect, Insulation Color Yellow, Insulation Coverage Full Coverage, Insulation Material Nylon, Maximum Temperature 194 Degrees F, Minimum Wire Size 12 AWG, Maximum Wire Size 10 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Tab, Termination Style Crimp, RoHS Compliant Yes, Seam Style Brazed, Standards UL Listed, Barrel Inside Diameter 0.142 in, Barrel Style Funnel Entry
