Shop VIEGA

3/4" X 3/4" Press Low Lead Bronze Spring Check Valve

  • Mfr # 79040

  • Zoro # G2517681

product price:
$
42.49
/ea

Key Features

Pipe Size
3/4"
Connection Type
Press x Press
Connection
P x P
Body Material
Bronze
Material of Construction
Bronze
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
79040
Zoro #
G2517681
UPC #
691514790404
Country of Origin
Germany

Dimensions

Pipe Size
3/4"
Pipe or Tube Size - Check Valves
3/4 in
Length
1"
Size
3/4"
Overall Length
2.95 in
Pipe or Tube Size
3/4 in
Connection Size - Side 2
3/4 in
Connection Size - Side 1
3/4 in
Nominal Valve Size
3/4 in
Wire Rope Length
2.95 in

Details

Connection Type
Press x Press
Connection
P x P
Body Material
Bronze
Material of Construction
Bronze
Max. Steam Pressure - Valves
Not Rated
Item
Check Valve
Body Material - Valves
Bronze
Compliance
ABS: America Bureau of Shipping, CRN 0A14541.5 A/B/C, CSA MSE-13, FM Class 1920, IAPMO PS117, ICC-ES PMG-1037, NSF 61, NSF 372, ULC/ORD 213
Max. Pressure
200 psi
Mechanism and Body Design
Inline Spring
Mounting Orientation - Check Valves
Horizontal, Vertical
Max. Temp. - Valves
200 Degrees F
Full Flow - Valves
No
Seal Material
EPDM
Cracking Pressure - Check Valves
0.500 psi
Seal Material - Check Valves
EPDM
Standards
Conforms to MSS SP-80
Cracking Pressure
0.5 psi
Item - Check Valves
Check Valve
Max. Water Pressure
200 psi
Sub-Category
Bronze
Max. Water Pressure - Valves
200 psi @ 200 Degrees F
Min. Temp. - Valves
0 Degrees F
Connection Type - Check Valves
Press x Press
Application - Valves
General Purpose
Flow Design
Single
Spring Material - Check Valves
Stainless Steel
Flow
30 gpm
Spring Material
Stainless Steel
Temp. Range
0 Degrees F to 250 Degrees F
Mounting Orientation
Horizontal, Vertical
Features
Smart Connect
Maximum Pressure - Steam
Not Rated
Connection Type - Side 2
Press
For Media
Potable Water
Vacuum Service Rating
Not Rated
Check Mechanism Material
Stainless Steel
Silent Check
Silent
Operating Temperature - Minimum
0 Degrees F
Operating Temperature - Maximum
200 Degrees F
Maximum Pressure - Operating
200 psi
3-A Standard Compliance
Not Rated
Connection Type - Side 1
Press
NSF Certifications for Food and Drinking Water
NSF 61
Includes Counterweight
No Counterweight
Valve Body Style
Inline
Valve Series
2974ZL

Description

Item - Check Valves Check Valve, Flow Design Single, Mechanism and Body Design Inline Spring, Body Material - Valves Bronze, Pipe or Tube Size 3/4 in, Connection Type Press x Press, Cracking Pressure 0.5 psi, Mounting Orientation Horizontal, Vertical, Seal Material EPDM, Max. Temp. - Valves 200 Degrees F, Min. Temp. - Valves 0 Degrees F, Max. Water Pressure - Valves 200 psi @ 200 Degrees F, Max. Steam Pressure - Valves Not Rated, Spring Material Stainless Steel, Full Flow - Valves No
