Strt, Steel, Press-fit2", Press-fit11/2"
Mfr # 25965
Zoro # G503964370
product price:Â
$
80.29
/ea
Key Features
Specific Fitting Shape
Straight Reducing Connector
Standards
ANSI/CAN/UL 213, ASME B31.1, ASME B31.3, ASME B31.9, ASTM F3226, CRN 23019.5 A/B/C, FM Class 1920, IAPMO PS 117, ICC-ES LC1002, NFPA 13, NFPA 13D, NFPA 13R
Fitting Side B Pipe Size
1 1/2 in
Fitting Shape
Straight
Fitting Side A Pipe Size
2 in
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 25965
- Zoro #
- G503964370
- UPC #
- 691514259659
- Country of Origin
- Germany
- Item
- Crimp Fitting
- Specific Fitting Shape
- Straight Reducing Connector
- Standards
- ANSI/CAN/UL 213, ASME B31.1, ASME B31.3, ASME B31.9, ASTM F3226, CRN 23019.5 A/B/C, FM Class 1920, IAPMO PS 117, ICC-ES LC1002, NFPA 13, NFPA 13D, NFPA 13R
- Fitting Shape
- Straight
- Fitting Material
- Carbon Steel
- Maximum Operating Pressure
- 200 psi
- O-Ring Material
- EPDM
- Includes Pre-Applied Thread Sealant
- Pre-Applied Thread Sealant Included
- Maximum Operating Temperature
- 250 Degrees F
- Fitting Side A Connection Type
- Press-Fit
- Application
- Non-Potable Water
- Fitting Side B Connection Type
- Press-Fit
- Finish/Coating
- Zinc Nickel-Plated
- Resistance Properties
- Corrosion-Resistant
- Minimum Operating Temperature
- 0 Degrees F
- Finish
- Zinc Nickel-Plated
- For Media Type
- Potable Water
- Connector Type
- Reducer
- Fitting Side 2 Connection Type
- Press-fit
- Operating Temperature - Minimum
- 0 Degrees F
- Operating Temperature - Maximum
- 250 Degrees F
- Operating Pressure - Maximum
- 200 psi
- Fitting Side 1 Connection Type
- Press-fit
Description
Crimp Fitting, Application Non-Potable Water, Fitting Side A Connection Type Press-Fit, Fitting Side B Connection Type Press-Fit, Fitting Material Carbon Steel, Fitting Side A Pipe Size 2 in, Fitting Side B Pipe Size 1 1/2 in, O-Ring Material EPDM, Specific Fitting Shape Straight Reducing Connector, Finish/Coating Zinc Nickel-Plated, Overall Length 5 9/32 in, Number of Bolt Holes Not Applicable, Flange Thickness Not Applicable, Maximum Operating Pressure 200 psi
