Terminal Block, 2.75" L, 1.55" W, 800V, Red

  • Mfr # 2202-1403

  • Zoro # G022935578

product price:  $3.15
/ea

Key Features

Housing Color
Red
For Minimum Wire Size
22 AWG
For Maximum Wire Size
12 AWG
Number of Poles
1
Wire Rope Length
2.75 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
2202-1403
Zoro #
G022935578
UPC #
-
Country of Origin
Germany

Dimensions

For Minimum Wire Size
22 AWG
For Maximum Wire Size
12 AWG
Wire Rope Length
2.75 in
Overall Width
1.55 in
For Channel Rail Size
35 mm
Overall Depth
0.2 in
Strip Length
15/32 in
Overall Length
2.75 in

Details

Housing Color
Red
Number of Poles
1
For Conductor Type
Solid, Stranded
For Conductor Material
Copper
Terminal Block Type
Pass-Through
2-Pole Jumper Compatibility
2002-400, 2002-402, 2002-402/000-005, 2002-402/000-006, 2002-423, 2002-423/000-005, 2002-423/000-006, 2002-424, 2002-424/000-005, 2002-424/000-006, 2002-433, 2002-434, 2002-435, 2002-436, 2002-437, 2002-438, 2002-439, 2002-440, 2002-472, 2002-473/011-000
Maximum Voltage
800 V
Number of Tiers
1
Standards
ABS 24-0095985-PDA, Aex UL 60079 E185892 (AEx eb IIC resp. Ex eb IIC), ATEX EN IEC 60079-0 PTB 18 ATEX 1005 U (II 2 G Ex eb IIC Gb bzw. I M 2 Ex eb I Mb), ATEX-Attestation of Conformity, BV IEC 60947 58186/A0 BV, CCA EN 60947 NTR NL 7950, CCC GB/T 3836.3 2020312313000169, CE, DEKRA EN 60947 71-147887, DNV GL TAE00003JT, IEC 60079 IECEx PTB 18.0012U (Ex eb IIC Gb and Ex eb I Mb), LR 19/20050, RoHS Compliant, UKCA, UL 1059 UL-CA-L45172-6189178-11508102-1
Circuit Protection Type
None
Minimum Operating Temperature
-60 Degrees C
Item
Terminal Block
Current
24 A
Housing Material
Polyamide 66
Number of Connections
4
Connection Type
Push-In
UL 94 Flammability Rating
V-0
6-Pole Jumper Compatibility
2002-406, 2002-406/000-005, 2002-406/000-006, 2002-406/020-000, 2002-476, 2002-481/011-000
Series
2202
Special Features
2 Jumper Slots, Front-Entry Wiring

Description

Terminal Block, Circuit Protection Type None, Connection Type Push-In, Current 24 A, For Minimum Wire Size 22 AWG, For Maximum Wire Size 12 AWG, Housing Color Red, Maximum Voltage 800 V, Mounting Type DIN Rail, Number of Poles 1, Number of Tiers 1, For Conductor Material Copper, For Conductor Type Solid, Stranded, Overall Depth 0.2 in, Overall Length 2.75 in, Overall Width 1.55 in
