  11. Square Turning Insert, Square, 3, SCMT, 2, Carbide
Walter Square Turning Insert, Square, 3, SCMT, 2, Carbide SCMT09T308-PS4 WAM20 - main

Square Turning Insert, Square, 3, SCMT, 2, Carbide

  • Mfr # SCMT09T308-PS4 WAM20

  • Zoro # G7935457

product price: $13.95
/ea
Sold in multiples of 10 for $139.50

Key Features

Insert Shape
Square
Insert Style
SCMT
Inscribed Circle
3
Insert Size
32.52
Chip-Breaker
Yes
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SCMT09T308-PS4 WAM20
Zoro #
G7935457
UPC #
-
Country of Origin
Germany

Dimensions

Insert Size
32.52
Corner Radius
2
Insert Thickness
0.1560"
Nose Radius
0.0310"
Mounting Hole Dia.
0.173"
Thickness
5/32 in
Cutting Edge Length
9.53mm

Details

Item
Square Turning Insert
Insert Shape
Square
Insert Style
SCMT
Inscribed Circle
3
Chip-Breaker
Yes
Grade
WAM20
Insert Material
Carbide
Insert Application
Medium
Rake
Positive
ISO Number
SCMT09T308-PS4
For Use With
Toolholders, Boring Bars
Workpiece Compatibility
Stainless (M), Super Alloy (S)
Stainless (M) Compatibility
Yes
Relief Angle
7 Degrees
Cast Iron (K) Compatibility
No
Hardened (H) Compatibility
No
Non Ferrous (N) Compatibility
No
Mounting Style
Screw
Steel (P) Compatibility
No
ANSI Number
SCMT3(2.5)2
Super Alloy (S) Compatibility
Yes
Coating
PVD
Cutting Direction
Neutral
No. of Edges
4
Manufacturer Grade
WAM20
Included Angle
90 Degrees
Finish - Machining
TiCN+Al2O3+HfN
Measurement System
Fractional Inch
Number of Cutting Edges
4
Primary Material Application ISO Code
M
Material - Machining
Carbide
Insert Holding Type
40 Degrees to 60 Degrees Countersink Hole
Coating Process
CVD
Cutting Application
Turning
Clearance Angle
7 Degrees
Shape
Square
ANSI Code
SCMT3(2.5)2-PS4
Primary Material Application
Stainless Steel
Chip-Breaker Code
PS4
Material
Carbide

Description

Square Turning Insert, Chip-Breaker Code PS4, Inscribed Circle 3/8 in, TiCN+Al2O3+HfN
