Touch-safe protection acc. to DIN VDE 57 106
Safe from finger touch
Wire cross-section, AWG, max.
AWG 14
Wire connection cross section AWG, min.
AWG 28
Rated voltage for surge voltage class / pollution degree II/2
400 V
Rated voltage for surge voltage class / pollution degree III/3
250 V
Comparative Tracking Index (CTI)
≥200
Volume resistance
4.50 mΩ
Max. relative humidity during storage
80 %
Rated voltage (Use group B / UL 1059)
300 V
Rated voltage (Use group D / UL 1059)
300 V
Plugging force/pole, max.
8 N
Rated current (Use group B / CSA)
15 A
Rated current, max. number of poles (Tu=40°C)
16 A
Temperature range, installation, max.
100 °C
Clamping range, min.
0.13 mm²
Rated current, max. number of poles (Tu=20°C)
19 A
Screwdriver blade
0.6 x 3.5
Rated impulse voltage for surge voltage class/ pollution degree II/2
4 kV
Operating temperature, max.
100 °C
Rated impulse voltage for surge voltage class/ contamination degree III/3
4 kV
Rated voltage (Use group B / CSA)
300 V
Tightening torque, min.
0.4 Nm
Rated cross-section
2.5 mm²
Colour chart (similar)
RAL 2000
Wire connection cross section AWG, max.
AWG 14
Screwdriver blade standard
DIN 5264
Short-time withstand current resistance
3 x 1s with 100 A
Pulling force/pole, max.
7 N
w. plastic collar ferrule, DIN 46228 pt 4, max.
1.5 mm²
Layer structure of plug contact
4-8µm Sn hot-dip tinned
Rated voltage for surge voltage class / pollution degree III/2
320 V
Rated voltage (Use group D / CSA)
300 V
Rated current, min. number of poles (Tu=20°C)
27 A
Flexible, min. H05(07) V-K
0.2 mm²
Conductor outlet direction
180°
Flexible, max. H05(07) V-K
1.5 mm²
Rated impulse voltage for surge voltage class/ pollution degree III/2
4 kV
Tightening torque, max.
0.5 Nm
Rated current (Use group B / UL 1059)
17 A
tested acc. to standard
IEC 60664-1, IEC 61984
Clamping range, max.
2.5 mm²
Operating temperature, min.
-50 °C
Insulating material group
IIIa
Rated current, min. number of poles (Tu=40°C)
24 A
Wire connection method
TOP connection
Wire cross-section, AWG, min.
AWG 26
Temperature range, installation, min.
-25 °C
w. wire end ferrule, DIN 46228 pt 1, min.
0.2 mm²
Storage temperature, max.
55 °C
Rated current (Use group D / UL 1059)
10 A
Solid, max. H05(07) V-U
2.5 mm²
w. wire end ferrule, DIN 46228 pt 1, max.
1.5 mm²
w. plastic collar ferrule, DIN 46228 pt 4, min.
0.2 mm²
Solid, min. H05(07) V-U
0.2 mm²
Certificate No. (cURus)
E60693
Plug gauge in accordance with EN 60999 a x b; ø
2.4 mm x 1.5 mm ; 2.4 mm
Max. clamping range
2.5 mm²
Pitch in inches (P)
0.2 inch
UL File Number Search
E60693
Rated current (Use group D / CSA)
15 A
Insulation strength
≥108 Ω
Storage temperature, min.
-25 °C
Type of connection
Field connection
UL 94 flammability rating
V-0
