  6. Terminal Block Interface Modules Trs 120Vac Rc 2Co Empty

This item is Discontinued.

Weidmuller Terminal Block Interface Modules Trs 120Vac Rc 2Co Empty 1124040000

Terminal Block Interface Modules Trs 120Vac Rc 2Co Empty (Discontinued)

  • Mfr # 1124040000
  • Zoro # G305797817
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
1124040000
Zoro #
G305797817
UPC #
-
Country of Origin
China

Dimensions

Depth (inches)
3.457 inch
Stripping length, rated connection
8 mm
Width (inches)
0.504 inch
Height (inches)
3.528 inch
Blade Size
size PH0

Details

Standards
DIN EN 50178
Impulse withstand voltage
6 kV (1.2/50µs)
Gauge to IEC 60947-1
A1, B1
Twin wire-end ferrules, max.
1 mm²
Dielectric strength to mounting rail
4 kVeff / 1 Min.
UL File Number Search
E223759
Dielectric strength of neighbouring contacts
2.5 kVeff
Wire cross-section, finely stranded, two clampable wires, max.
1 mm²
Conductor cross-section, flexible, AEH (DIN 46228-1), min.
0.25 mm²
Wire connection cross section, finely stranded, max.
2.5 mm²
Pitch in mm (P)
5 mm
Dielectric strength, Input/Output
1.2 kVeff / 5 s
Wire connection cross-section, finely stranded, min.
0.14 mm²
Type of conductor
rigid copper conductor, flexible copper conductor
Wire cross-section, finely stranded, max. (AWG)
AWG 14
Storage temperature, max.
85 °C
Protective circuit
Rectifier, RC element
RC filter
94 Ω / 100 nF
Creepage and clearance distance input to output
≥5.5 mm
Operating Temperature
-40°C...60°C
Wire connection cross section AWG, max.
AWG 14
Protection degree
IP20
Ambient temperature (operational), max.
60 °C
Rated switching voltage
250 V AC
Twin wire-end ferrules, min.
0.5 mm²
Operating temperature, max.
60 °C
Connection cross-section AWG, min.
AWG 26
Pollution severity level
2
Tightening torque, max.
0.4 Nm
Status indicator
Green LED
Clamping range, rated connection
1.5 mm²
Contact Type
2 CO contact
Conductor cross-section, flexible, AEH (DIN 46228-1), max.
2.5 mm²
Wire cross-section, solid, max.
2.5 mm²
Operating temperature, min.
-40 °C
Coil voltage of the replacement relay
110 V DC
Storage temperature, min.
-40 °C
Connection cross-section AWG, max.
AWG 14
Coil voltage of the replacement relay deviating from the rated control voltage
Yes
Colour
black
Clamping range, max.
2.5 mm²
Wire connection method
Screw connection
UL 94 flammability rating
V-0
Certificate No. (cURus)
E223759
Rated voltage
300 V
Wire connection cross section, finely stranded, two clampable wires, min.
0.5 mm²
Wire cross-section, finely stranded, min. (AWG)
AWG 26
Rated control voltage
120 V AC± 10 %
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.
2.5 mm²
Continuous current
10A
Surge voltage category
III
Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.
0.25 mm²
Pollution severity
2
Output current derating (ohmic)
6 A @ 60°C, 8 A @ 50°C
Storage temperature
-40°C...85°C
Clamping range, min.
0.14 mm²
Wire cross-section, solid, min.
0.14 mm²
Rail
TS 35
Approvals
CE, cURus, EAC
Wire connection cross section AWG, min.
AWG 26
