  11. Indexable Boring Bar, FSRI3123560R, 3 1/2 in L, High Speed Steel, Triangle Insert Shape
Widia Indexable Boring Bar, FSRI3123560R, 3 1/2 in L, High Speed Steel, Triangle Insert Shape FSRI3123560R - main

Indexable Boring Bar, FSRI3123560R, 3 1/2 in L, High Speed Steel, Triangle Insert Shape

  • Mfr # FSRI3123560R

  • Zoro # G3576229

product price: $266.99
/ea
Free Shipping & Returns

Key Features

Overall Length
3 1/2 in
Shank Material
High Speed Steel
Insert Shape
Triangle
ANSI Code
FSRI3123560R
Rake
0 Degrees Axial, 0 Degrees Radial
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
FSRI3123560R
Zoro #
G3576229
UPC #
4021169357350
Country of Origin
United States

Dimensions

Overall Length
3 1/2 in
Insert Size
130805
Shank Dia.
5/16 in
Min. Bore Dia.
0.4070 in
Cutting Height
0.0100 in
Shank Length
3 in
Insert Cutting Edge Length
7.04mm

Details

Item
Indexable Boring Bar
Shank Material
High Speed Steel
Insert Shape
Triangle
ANSI Code
FSRI3123560R
Rake
0 Degrees Axial, 0 Degrees Radial
Lead Angle
30 Degrees
Left/Right Hand
Right Hand
Type
Screw Clamping
Cutting Direction
Right Hand
Insert Clearance Angle
15 Degrees
Number of Inserts
1
Insert Holding Type
Screw On
Insert Style
TD
ISO Number
FSRI3123560R
Number of Coolant Holes
1
Side Cutting Edge Angle
30 Degrees
Center to Cutting Tip
0.2360 in
Cutting Application
Turning
Compatible Hardware
T7 Insert Screw
Approach Angle
60 Degrees
Coolant Fed
Coolant Through
Measurement System
Fractional Inch

Description

Indexable Boring Bar, Insert Shape Triangle, Overall Length 3 1/2 in, FSRI3123560R, 60 Degrees , 0.2360 in, T7 Insert Screw, Coolant Through, Turning, Right Hand
