  6. Indexable Boring Bar, QSOI375750150R, 3-3/4 in L, High Speed Steel, Triangle Insert Shape
Widia Indexable Boring Bar, QSOI375750150R, 3-3/4 in L, High Speed Steel, Triangle Insert Shape QSOI375750150R - main

Indexable Boring Bar, QSOI375750150R, 3-3/4 in L, High Speed Steel, Triangle Insert Shape

  • Mfr # QSOI375750150R

  • Zoro # G3573620

product price:  $244.99
/ea
Free Shipping & Returns

Key Features

Overall Length
3-3/4 in
Shank Material
High Speed Steel
Insert Shape
Triangle
ANSI Code
QSOI375750150R
Insert Size
21505
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
QSOI375750150R
Zoro #
G3573620
UPC #
4021169376856
Country of Origin
United States

Dimensions

Overall Length
3-3/4 in
Insert Size
21505
Shank Dia.
3/4 in
Min. Bore Dia.
3/4 in
Cutting Height
0.0075 in
Max. Bore Depth
1-1/2 in
Insert Cutting Edge Length
11.00mm
Shank Length
2-1/4 in

Details

Item
Indexable Boring Bar
Shank Material
High Speed Steel
Insert Shape
Triangle
ANSI Code
QSOI375750150R
Left/Right Hand
Right Hand
Rake
0 Degrees Radial, 5 Degrees Axial
Type
Screw Clamping
Lead Angle
0 Degrees
Cutting Direction
Right Hand
Cutting Application
Turning
Coolant Fed
Coolant Through
ISO Number
QSOI375750150R
Insert Clearance Angle
11 Degrees
Approach Angle
90 Degrees
Compatible Hardware
T9 Insert Screw
Side Cutting Edge Angle
0 Degrees
Insert Holding Type
Screw On
Center to Cutting Tip
0.0240 in
Insert Style
TP
Number of Inserts
1
Measurement System
Fractional Inch

Description

Indexable Boring Bar, Insert Shape Triangle, Overall Length 3-3/4 in, QSOI375750150R, 90 Degrees , 0.0240 in, T9 Insert Screw, Coolant Through, Turning, Right Hand

Restrictions

WARNING: Cancer For more information go to www.P65Warnings.ca.gov
