Widia Indexable Insert Drill, 1-1/4", TCF TCF1188R2SLR125E - main

Indexable Insert Drill, 1-1/4", TCF

  • Mfr # TCF1188R2SLR125E

  • Zoro # G3777074

product price: $553.99
/ea
Free Shipping & Returns

Key Features

Diameter
1-1/4"
Ratio
2xD
Shank Dia.
1-1/4 in
Shank Length
60.00mm
Cutting Direction
Right Hand
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TCF1188R2SLR125E
Zoro #
G3777074
UPC #
4050839892204
Country of Origin
Bulgaria

Dimensions

Diameter
1-1/4"
Shank Dia.
1-1/4 in
Shank Length
60.00mm
Overall Length
153.60mm
Min. Drill Dia.
30.18mm
Flute Length
88.60mm
Max. Drilling Depth
61.45mm
Depth x Dia. Ratio
2xD
Max. Drill Dia.
31.18mm

Details

Item
Indexable Insert Drill
Ratio
2xD
Cutting Direction
Right Hand
Mounting Style
Screw Clamp
Number of Inserts
2
Flanged Shank
Yes
Coolant Fed
Coolant Through
Flute Type
Slow Spiral
Central Insert Style
TCF
Toolholder Style
TCF
ANSI Code
TCF1188R2SLR125E
Number of Coolant Holes
2
Drilling Application
45 Degrees Corner, Blind Hole, Chain, Convex, Cross Hole, Half Cylindrical, Inclined Entry, Inclined Exit, X-Offset
ISO Number
TCF1188R2SLR125E
Shank Type - Machining
Round with Flat and Side Lock
Spiral Direction
Right Hand
Measurement System
Fractional Inch

Description

Indexable Insert Drill, 2xD, Max. Drilling Depth 61.45mm, TCF1188R2SLR125E, TCF, Coolant Through
