  11. Indexable Insert Drill, 1-1/4", TCF
Widia Indexable Insert Drill, 1-1/4", TCF TCF1280R3SLR125E - main

Indexable Insert Drill, 1-1/4", TCF

  • Mfr # TCF1280R3SLR125E

  • Zoro # G3779402

product price: $565.99
/ea
Free Shipping & Returns

Key Features

Diameter
1-1/4"
Ratio
3xD
Overall Length
193.07mm
Shank Dia.
1-1/4 in
Mounting Style
Screw Clamp
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TCF1280R3SLR125E
Zoro #
G3779402
UPC #
4050839893379
Country of Origin
Bulgaria

Dimensions

Diameter
1-1/4"
Overall Length
193.07mm
Shank Dia.
1-1/4 in
Shank Length
60.00mm
Flute Length
128.10mm
Min. Drill Dia.
32.54mm
Max. Drilling Depth
98.78mm
Depth x Dia. Ratio
3xD
Max. Drill Dia.
33.54mm

Details

Item
Indexable Insert Drill
Ratio
3xD
Mounting Style
Screw Clamp
Cutting Direction
Right Hand
Toolholder Style
TCF
Spiral Direction
Right Hand
Central Insert Style
TCF
Number of Coolant Holes
2
ISO Number
TCF1280R3SLR125E
Coolant Fed
Coolant Through
ANSI Code
TCF1280R3SLR125E
Drilling Application
45 Degrees Corner, Blind Hole, Chain, Convex, Cross Hole, Half Cylindrical, Inclined Entry, Inclined Exit, X-Offset
Flute Type
Slow Spiral
Shank Type - Machining
Round with Flat and Side Lock
Number of Inserts
2
Flanged Shank
Yes
Measurement System
Fractional Inch

Description

Indexable Insert Drill, 3xD, Max. Drilling Depth 98.78mm, TCF1280R3SLR125E, TCF, Coolant Through
