Widia Indexable Insert Drill, 1.25 in, TCF TCF1125R2SLR125D - main

Indexable Insert Drill, 1.25 in, TCF

  • Mfr # TCF1125R2SLR125D

  • Zoro # G3762243

product price: $494.99
/ea
Free Shipping & Returns

Key Features

Diameter
1-1/4"
Ratio
2xD
Shank Length
2.3622 in
Shank Dia.
1.25 in
Overall Length
5.9740 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TCF1125R2SLR125D
Zoro #
G3762243
UPC #
4050839887347
Country of Origin
Bulgaria

Dimensions

Diameter
1-1/4"
Shank Length
2.3622 in
Shank Dia.
1.25 in
Overall Length
5.9740 in
Flute Length
3.4150 in
Max. Drilling Depth
2.2900 in
Min. Drill Dia.
1-1/8 in
Depth x Dia. Ratio
2xD
Max. Drill Dia.
1.1644"

Details

Item
Indexable Insert Drill
Ratio
2xD
Cutting Direction
Right Hand
Mounting Style
Screw Clamp
Spiral Direction
Right Hand
Number of Coolant Holes
2
Flanged Shank
Yes
Central Insert Style
TCF
ANSI Code
TCF1125R2SLR125D
Toolholder Style
TCF
ISO Number
TCF1125R2SLR125D
Drilling Application
45 Degrees Corner, Blind Hole, Chain, Convex, Cross Hole, Half Cylindrical, Inclined Entry, Inclined Exit, X-Offset
Coolant Fed
Coolant Through
Shank Type - Machining
Round with Flat and Side Lock
Flute Type
Slow Spiral
Number of Inserts
2
Measurement System
Fractional Inch

Description

Indexable Insert Drill, 2xD, Max. Drilling Depth 2.2900 in, TCF1125R2SLR125D, TCF, Coolant Through
