Indexable Profiling End Mill, VSM11 Series, High Speed Steel, 11.53mm Depth of Cut
Mfr # VSM11D016Z02A16XD11L100
Zoro # G3800831
product price:Â $346.99
/ea
Free Shipping & Returns
Key Features
Series
VSM11
Overall Length
100.00mm
Depth of Cut
11.53mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
VSM11D016Z02A16XD11L100
Zoro #
G3800831
UPC #
4050839640454
Country of Origin
China
Dimensions
Overall Length
100.00mm
Depth of Cut
11.53mm
Insert Size
110408
Shank Dia.
16.00mm
Neck Dia.
13.81mm
Min. Cutting Dia.
16.00mm
Head Projection Length
31.00mm
Shank Length
69.00mm
Description
Indexable Profiling End Mill, Depth of Cut 11.53mm, Shank Dia. 16.00mm, Overall Length 100.00mm, ANSI Code VSM11D016Z02A16XD11L100, Compatible Hardware Insert Screw M2.5x0.45 x 5.9 T8, Torx Wrench TX8, Coolant Fed Coolant Through, Cutting Application Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side/Shoulder Milling: Square End
