Indexable Profiling End Mill, VSM17 Series, High Speed Steel, 15.90mm Depth of Cut
Mfr # VSM17D080Z06S27XD17
Zoro # G3789491
product price:Â $966.99
/ea
Free Shipping & Returns
Key Features
Series
VSM17
Overall Length
50.00mm
Depth of Cut
15.90mm
Material - Machining
High Speed Steel
Insert Size
1704
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
VSM17D080Z06S27XD17
Zoro #
G3789491
UPC #
4056544118127
Country of Origin
Unknown
Dimensions
Overall Length
50.00mm
Depth of Cut
15.90mm
Insert Size
1704
Arbor Dia.
27.00mm
Hub Outside Dia.
60.00mm
Details
Item
Indexable Profiling End Mill
Series
VSM17
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Rake
-4.9 Degrees Radial, 13 Degrees Axial
Features
Effective Internal Coolant Feature, Increased Ramping Capability, Precisely Reaching the Cutting Edge, Superior Wall and Surface Finish Capabilities, True 90 Degrees Capability
Cutting Application
Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End
Max. Speed
19,500 RPM
Number of Inserts
6
Coolant Fed
Coolant Through
ISO Number
VSM17D080Z06S27XD17
Side Cutting Edge Angle
90 Degrees
Insert Holding Type
Screw
Insert Style
XD.T PE R
Compatible Hardware
Insert Screw M4x0.7 x 8.4 T15, SHCS M12 1.75P x 30, SHCS with Coolant Groove, Torx Wrench TX15
ANSI Code
VSM17D080Z06S27XD17
Description
Indexable Profiling End Mill, Depth of Cut 15.90mm, Overall Length 50.00mm, ANSI Code VSM17D080Z06S27XD17, Compatible Hardware Insert Screw M4x0.7 x 8.4 T15, SHCS M12 1.75P x 30, SHCS with Coolant Groove, Torx Wrench TX15, Coolant Fed Coolant Through, Cutting Application Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End
