Indexable Profiling End Mill, VXF Series, High Speed Steel, 2.50mm Depth of Cut
Mfr # VXF063Z05S22XD12
Zoro # G3792921
product price:Â $729.99
/ea
Free Shipping & Returns
Key Features
Series
VXF
Overall Length
40.00mm
Depth of Cut
2.50mm
Material - Machining
High Speed Steel
Insert Size
120512
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
VXF063Z05S22XD12
Zoro #
G3792921
UPC #
4061779080071
Country of Origin
India
Dimensions
Overall Length
40.00mm
Depth of Cut
2.50mm
Insert Size
120512
Max. Cutting Dia.
63.00mm
Arbor Dia.
22.00mm
Hub Outside Dia.
52.50mm
Details
Item
Indexable Profiling End Mill
Series
VXF
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
90 Degrees Square
Rake
-5 Degrees Radial, 5 Degrees Axial
Cutting Application
Counter Boring, Face Milling, Helical Milling, Inclined Square End Mill, Plunge Milling, Pocketing, Ramping: Blank, Side and Face Milling, Spiral Circular
Coolant Fed
Coolant Through
Insert Holding Type
Screw
Number of Inserts
5
ISO Number
VXF063Z05S22XD12
Compatible Hardware
Anti-Seize Lubricant, Insert Screw M4.5x0.75 x 11 T20, Torx Driver
Max. Speed
19,500 RPM
ANSI Code
VXF063Z05S22XD12
Insert Style
XDPT ERMM
Description
Indexable Profiling End Mill, Max. Cutting Dia. 63.00mm, Depth of Cut 2.50mm, Overall Length 40.00mm, ANSI Code VXF063Z05S22XD12, Compatible Hardware Anti-Seize Lubricant, Insert Screw M4.5x0.75 x 11 T20, Torx Driver, Coolant Fed Coolant Through, Cutting Application Counter Boring, Face Milling, Helical Milling, Inclined Square End Mill, Plunge Milling, Pocketing, Ramping: Blank, Side and Face Milling, Spiral Circular
