Widia

Milling Insert, Hexagon

product price: $17.99
/ea
Sold in multiples of 5 for $89.95
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Workpiece Compatibility Cast Iron (K), Stainless (M), Steel (P)
  • Mounting Hole Dia. 0.1970 in
  • Coating Al2O3
  • Non Ferrous (N) Compatibility No
  • ISO Number HNPJ090543ANSNHD
See all product information

Product Information

Dimensions

Mounting Hole Dia. 0.1970 in
Nose Radius 0.171"
Insert Size 53511
Through Hole Inside Dia. 0.1970 in
Corner Radius 0.1709 in
Cutting Edge Length 8.50mm

Details

Workpiece Compatibility Cast Iron (K), Stainless (M), Steel (P)
Coating Al2O3
Non Ferrous (N) Compatibility No
ISO Number HNPJ090543ANSNHD
Item Hexagon Milling Insert
Rake Positive
Hardened (H) Compatibility No
Steel (P) Compatibility Yes
Grade WP35CM
Chip-Breaker Yes
Mounting Style Screw Clamp
Cutting Direction Right Hand
Stainless (M) Compatibility Yes
Insert Material Carbide
No. of Edges 12
Insert Shape Hexagon
Inscribed Circle 5/8 in
Insert Application Roughing
For Use With M1200 Series Face Mills
Super Alloy (S) Compatibility No
Insert Thickness 0.214"
Insert Style HNPJ
ANSI Number HNPJ53511ANSNHD
Cast Iron (K) Compatibility Yes
Lead Angle 30 Degrees ANSI, 60 Degrees ISO
Series M1200
For Toolholder M1200HF200Z04S075HN09, M1200HF250Z05S075HN09, M1200HF300Z06S100HN09, M1200HF400Z08S150HN09, M1200HF500Z09S150HN09, M1200HF600Z12S200HN09
Finish - Machining Al2O3
Number of Cutting Edges 12
Material - Machining Carbide
Wiper Insert Yes
Thickness 0.2142 in
Insert Holding Type Screw Clamp
Primary Material Application ISO Code K, P
Chip-Breaker Style Double Sided
Coating Process CVD
Shape Hexagon
Cutting Application Roughing
Measurement System Fractional Inch
Chip-Breaker Code HD
Clearance Angle 0 Degrees
Secondary Material Application Stainless Steel
Manufacturer Grade WP35CM
Hole Type 70 Degrees to 90 Degrees Double Countersink Hole
Primary Material Application Cast Iron, Steel
Included Angle 120 Degrees
ANSI Code HNPJ53511ANSNHD
Secondary Material Application ISO Code M

Description

Hexagon Milling Insert, Inscribed Circle 5/8 in
