Modular Drill, 63.00mm Drill Depth
Mfr # TDMX200R3SL25M
Zoro # G3822960
product price: $507.99
/ea
Free Shipping & Returns
Key Features
Diameter
25.00mm
ISO Number
TDMX200R3SL25M
Cutting Direction
Right Hand
Body Length
56.00mm
Overall Length
155.00mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
TDMX200R3SL25M
Zoro #
G3822960
UPC #
4061779042109
Country of Origin
Germany
Dimensions
Diameter
25.00mm
Body Length
56.00mm
Overall Length
155.00mm
Max. Dia.
20.9990mm
Shank Dia.
25.00mm
Min. Drill Dia.
19.00mm
Max. Drilling Depth
21.00mm
Flute Length
63.00mm
Shank Dia. Measurement System
Metric
Depth x Dia. Ratio
3xD
Shank Length
56.00mm
Seat Size
E
Max. Drill Dia.
63.00mm
Description
Exchangeable Drill Tip, TDMX, Shank Type - Machining Round with Flat and Side Lock, High Speed Steel
