  11. Modular Drill, 93.00mm Drill Depth
Widia Modular Drill, 93.00mm Drill Depth TDMX300R3SL32M - main

Modular Drill, 93.00mm Drill Depth

  • Mfr # TDMX300R3SL32M

  • Zoro # G3824379

product price: $866.99
/ea
Free Shipping & Returns

Key Features

Diameter
32.00mm
ISO Number
TDMX300R3SL32M
Cutting Direction
Right Hand
Overall Length
204.00mm
Max. Dia.
30.9990mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TDMX300R3SL32M
Zoro #
G3824379
UPC #
4061779043502
Country of Origin
Germany

Dimensions

Diameter
32.00mm
Overall Length
204.00mm
Max. Dia.
30.9990mm
Body Length
60.00mm
Shank Dia.
32.00mm
Depth x Dia. Ratio
3xD
Flute Length
93.00mm
Shank Dia. Measurement System
Metric
Min. Drill Dia.
30.00mm
Max. Drilling Depth
31.00mm
Shank Length
60.00mm
Seat Size
O
Max. Drill Dia.
93.00mm

Description

Exchangeable Drill Tip, TDMX, Shank Type - Machining Round with Flat and Side Lock, High Speed Steel
