Thread Turning Toolholder, A-DDQ-KC, HSS
Mfr # A32SDDQNL15KC06
Zoro # G3820124
product price: $456.99
/ea
Free Shipping & Returns
Key Features
Insert Size
150608
Cutting Direction
Left Hand
Rake
-10 Degrees Axial, -12 Degrees Radial
ISO Number
A32SDDQNL15KC06
Shank Dia.
32.00mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
A32SDDQNL15KC06
Zoro #
G3820124
UPC #
4050841468770
Country of Origin
India
Dimensions
Insert Size
150608
Shank Dia.
32.00mm
Cutting Dia.
1.2600mm
Overall Length
250.00mm
Min. Bore Dia.
40.00mm
Shank Length
205.44mm
Insert Cutting Edge Length
15.50mm
Details
Item
Indexable Thread Turning Tool Holder
Cutting Direction
Left Hand
Rake
-10 Degrees Axial, -12 Degrees Radial
ISO Number
A32SDDQNL15KC06
Insert Style
DN..
Coolant Fed
Coolant Through
Toolholder Style
A-DDQ-KC
Insert Holding Type
Top Clamping
Center to Cutting Tip
0 in
Shank Material
High Speed Steel
Cutting Application
Back Boring, Inside Diameter Chamfering, Inside Diameter Chamfering and Profiling
ANSI Code
A32SDDQNL15KC06
Number of Coolant Holes
1
Measurement System
Metric
Description
Indexable Thread Turning Tool Holder, Insert Style DN.., Left Hand, Back Boring, Inside Diameter Chamfering, Inside Diameter Chamfering and Profiling, ANSI Code A32SDDQNL15KC06, Center to Cutting Tip 0 in, Coolant Fed Coolant Through
