Enclosure Cover, 7 in. H x 13 in. W x 15 in. L, Aluminum

  • Mfr # BN4141206AL
  • Zoro # G7335477
product price:
$
577.99
/ea
Free Shipping & Returns

Key Features

Dimension
7 in. H x 13 in. W x 15 in. L
Height
7 in
Width
13 in
Knockouts
No
Type
Enclosure
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
BN4141206AL
Zoro #
G7335477
UPC #
786725376858
Country of Origin
United States

Dimensions

Dimension
7 in. H x 13 in. W x 15 in. L
Height
7 in
Width
13 in
Length
15 in
Depth
15 in
Actual Height
6.500 in
Each - Width
12.500 in
Actual Depth
14.5 in
Actual Width
12.500 in

Details

Item
Enclosure Cover
Knockouts
No
Type
Enclosure
Mounting
External Mounting Plates
Material
Aluminum
NEMA Enclosure Type
NEMA 4X
Application
Designed as an instrument housing or junction box for electrical, electronic, or pneumatic components. It is ideal for applications where a lightweight, corrosion resistant enclosure is required.
Features
Bodies and doors fabricated from .080-inch thick (2 millimeters) 5052-H32 aluminum; Continuously welded seams ground smooth, less holes or knockouts; Closed cell oil resistant neoprene gasket; External mounting plates, top and bottom of enclosure; Weldnuts are provided to secure optional panel; Stainless steel screws and clamps on four sides of cover to assure water tight seal; Optional panels and terminal kits must be ordered separately; Grounding provisions provided
Standard
cULus;IEC
Series
BN4-AL
Construction
Continuously Welded Seams
Mounting Type
External Mounting Plates
Listings
UL, CSA
Certified Listed
cULus;IEC
Nema Rating
4X
UL Listed
Yes
Latches Type
Clamps
Cubic Capacity
1365 cu.in
Number of Doors (Fixed)
1
Cover Type
Lift Off

Description

Designed as an instrument housing or junction box for electrical,electronic, or pneumatic components. It is ideal for applicationswhere alightweight, corrosion resistant enclosure is required.
