  5. Low Pressure Gauge, 0 to 100 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material
Winters Low Pressure Gauge, 0 to 100 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material PLP304 - main

Low Pressure Gauge, 0 to 100 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material

  • Mfr # PLP304

  • Zoro # G1937422

product price:  $44.49
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PLP304
Zoro #
G1937422
UPC #
628311203189
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Case Diameter
2.625 in
Manufacturer Warranty Length
5 yr
Nominal Dial Size
2 1/2 in
Case Depth
1.9 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Low Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Air Compressors, Air Filters, Regulators and Respirators, Vacuum Applications
Gauge Case Material
Steel
Series
PLP
Lens Material
Polycarbonate
Primary Pressure Range
0 to 100
Primary Scale Units
in wc
IP/NEMA Rating
IP52
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
For Use With
Air Compressors, Air Filters, Gas Burners, Respirators, Suction Regulators, Vacuum Ovens, Vacuum Pumps
Gauge Primary Range Smallest Graduation
5 in-oz
Case Color
Black
Smallest Graduation
2 in wc/1 in-oz
Calibration Certificate Included
No
Gauge Secondary Range Values
0 to 70,000
Gauge Special Options
Diaphragm
Gauge Primary Range Numbered Graduations
10/10
Characteristics
Suitable for Corrosive and Non Corrosive Gaseous Media, Natural Gas and Propane Pressure, Air Flow Indication, Leak Detection
Case Material
Steel
Socket Material
Brass
Gauge Application
For Natural Gas & Other Gases
Standards
CRN Registered
Connection Type
MNPT
Field Fillable
No
Cleaned for Oxygen Service
No
Dry Dampening Feature
None
Compatible Process Media
Gaseous
Vibration Resistance
None
Includes Vent Plug
No
Pressure Range Type
Pressure
Adjustable Pointer
No
Pointer Material
Aluminum
Process Temperature Range
-40 Degrees to 150 Degrees F
Gauge Case Liquid
None
Sensor Type
Diaphragm
Scale Type
Dual
Case Finish
Painted
Primary Scale Minor Graduations
5
Accuracy Grade
ASME B40.100 Grade B
Dial Color
White
Sensor Material
Phosphor Bronze
Includes Calibration Certificate
No
Removable Bezel
No
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Freeze Resistant Movement
No
Pointer Color
Black
Process Connection Gender
Male
Dial Face Material
Aluminum
Pressure Gauge Type
Low Pressure Gauge
Primary Scale Numeric Increments
10
Accuracy Scale
Mid-Scale
Pointer Characteristics
Aluminum, Anodized Black
Bezel Mounting Type
No Bezel
Secondary Pressure Range
0 to 58
Secondary Scale Units
oz/in2
Includes Mounting Hardware
No
Over-Pressure Limit
30% of Full Scale
Operating Temperature Range
-40 Degrees to 150 Degrees F
Process Media Temperature - Minimum
-40 Degrees F
Operating Temperature - Maximum
150 Degrees F
NEMA Enclosure Rating
5
Case Liquid
None
Operating Temperature - Minimum
-40 Degrees F
IP Rating
IP52
Compatible with Brand
Universal
Secondary Scale Pressure Measurement - Minimum
0 oz/sq in
Secondary Scale Pressure Measurement - Maximum
58 oz/sq in
Primary Scale Pressure Measurement - Maximum
100 in wc
Primary Scale Pressure Measurement - Minimum
0 in wc
Process Media Temperature - Maximum
150 Degrees F

Description

Low Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating IP52, Primary Pressure Range 0 to 100, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Low Pressure Gauge, Liquid-Filled Case No
