Winters Low Pressure Gauge, 0 to 200 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material PLP303 - main
Shop WINTERS

Low Pressure Gauge, 0 to 200 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material

  • Mfr # PLP303

  • Zoro # G1937395

product price:  $40.99
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PLP303
Zoro #
G1937395
UPC #
628311203196
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Case Diameter
2.625 in
Nominal Dial Size
2 1/2 in
Case Depth
1.9 in
Manufacturer Warranty Length
5 yr
Nominal Dial Diameter
2 1/2 in

Details

Item
Low Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Air Compressors, Air Filters, Regulators and Respirators
Gauge Case Material
Steel
Series
PLP
Lens Material
Polycarbonate
Primary Pressure Range
0 to 200
Primary Scale Units
in wc
IP/NEMA Rating
IP52
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
For Use With
Air Compressors, Air Filters, Gas Burners, Respirators, Suction Regulators, Vacuum Ovens, Vacuum Pumps
Gauge Secondary Range Values
0 to 70,000
Case Color
Black
Smallest Graduation
4 in wc/2 in-oz
Gauge Primary Range Smallest Graduation
10 in-oz
Gauge Primary Range Numbered Graduations
20/20
Gauge Special Options
Diaphragm
Calibration Certificate Included
No
Characteristics
Suitable for Corrosive and Non Corrosive Gaseous Media, Natural Gas and Propane Pressure, Air Flow Indication, Leak Detection
Gauge Application
For Natural Gas & Other Gases
Case Material
Steel
Socket Material
Brass
Connection Type
MNPT
Standards
CRN Registered
Removable Bezel
No
Freeze Resistant Movement
No
Gauge Case Liquid
None
Dry Dampening Feature
None
Secondary Pressure Range
0 to 116
Includes Mounting Hardware
No
Bezel Mounting Type
No Bezel
Primary Scale Minor Graduations
10
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Accuracy Grade
ASME B40.100 Grade B
Includes Calibration Certificate
No
Process Connection Gender
Male
Sensor Type
Diaphragm
Case Finish
Painted
Process Temperature Range
-40 Degrees to 150 Degrees F
Includes Vent Plug
No
Dial Color
White
Adjustable Pointer
No
Pointer Material
Aluminum
Pressure Gauge Type
Low Pressure Gauge
Field Fillable
No
Pressure Range Type
Pressure
Vibration Resistance
None
Pointer Characteristics
Aluminum, Anodized Black
Scale Type
Dual
Dial Face Material
Aluminum
Pointer Color
Black
Secondary Scale Units
oz/in2
Compatible Process Media
Gaseous
Primary Scale Numeric Increments
20
Over-Pressure Limit
30% of Full Scale
Cleaned for Oxygen Service
No
Accuracy Scale
Mid-Scale
Sensor Material
Phosphor Bronze
Operating Temperature Range
-40 Degrees to 150 Degrees F
Primary Scale Pressure Measurement - Minimum
0 in wc
Operating Temperature - Maximum
150 Degrees F
Process Media Temperature - Minimum
-40 Degrees F
IP Rating
IP52
Case Liquid
None
Primary Scale Pressure Measurement - Maximum
200 in wc
Compatible with Brand
Universal
NEMA Enclosure Rating
5
Operating Temperature - Minimum
-40 Degrees F
Secondary Scale Pressure Measurement - Maximum
116 oz/sq in
Secondary Scale Pressure Measurement - Minimum
0 oz/sq in
Process Media Temperature - Maximum
150 Degrees F

Description

Low Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating IP52, Primary Pressure Range 0 to 200, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Low Pressure Gauge, Liquid-Filled Case No
