  9. Low Pressure Gauge, 0 to 200 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location
Winters Low Pressure Gauge, 0 to 200 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location PLP346 - main

Low Pressure Gauge, 0 to 200 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location

  • Mfr # PLP346

  • Zoro # G1936582

product price: $42.30
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PLP346
Zoro #
G1936582
UPC #
628311203080
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Nominal Dial Size
2 1/2 in
Case Diameter
2.625 in
Manufacturer Warranty Length
5 yr
Case Depth
1.9 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Low Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Type
NPT
Application
Air Compressors, Air Filters, Regulators and Respirators, Vacuum Applications
Gauge Case Material
Steel
Series
PLP
Lens Material
Polycarbonate
Primary Pressure Range
0 to 200
Primary Scale Units
in wc
IP/NEMA Rating
IP52
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Gauge Primary Range Smallest Graduation
10 in-oz
For Use With
Air Compressors, Air Filters, Gas Burners, Respirators, Suction Regulators, Vacuum Ovens, Vacuum Pumps
Gauge Primary Range Numbered Graduations
20/20
Calibration Certificate Included
No
Gauge Special Options
Diaphragm
Gauge Secondary Range Values
0 to 70,000
Case Color
Black
Smallest Graduation
4 in wc/2 in-oz
Gauge Application
For Natural Gas & Other Gases
Characteristics
Suitable for Corrosive and Non Corrosive Gaseous Media, Natural Gas and Propane Pressure, Air Flow Indication, Leak Detection
Socket Material
Brass
Case Material
Steel
Connection Type
MNPT
Standards
CRN Registered
Cleaned for Oxygen Service
No
Compatible Process Media
Gaseous
Scale Type
Dual
Pointer Material
Aluminum
Includes Calibration Certificate
No
Freeze Resistant Movement
No
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Process Connection Gender
Male
Includes Vent Plug
No
Secondary Pressure Range
0 to 116
Dial Color
White
Case Finish
Painted
Over-Pressure Limit
30% of Full Scale
Removable Bezel
No
Pointer Color
Black
Field Fillable
No
Bezel Mounting Type
No Bezel
Dial Face Material
Aluminum
Process Temperature Range
-40 Degrees to 150 Degrees F
Secondary Scale Units
oz/in2
Vibration Resistance
None
Dry Dampening Feature
None
Pointer Characteristics
Aluminum, Anodized Black
Accuracy Scale
Mid-Scale
Includes Mounting Hardware
No
Gauge Case Liquid
None
Pressure Gauge Type
Low Pressure Gauge
Sensor Type
Diaphragm
Pressure Range Type
Vacuum
Primary Scale Minor Graduations
10
Accuracy Grade
ASME B40.100 Grade B
Adjustable Pointer
No
Primary Scale Numeric Increments
20
Sensor Material
Phosphor Bronze
Operating Temperature Range
-40 Degrees to 150 Degrees F
Secondary Scale Pressure Measurement - Maximum
116 oz/sq in
Primary Scale Pressure Measurement - Maximum
200 in wc
Primary Scale Pressure Measurement - Minimum
0 in wc
Secondary Scale Pressure Measurement - Minimum
0 oz/sq in
Compatible with Brand
Universal
IP Rating
IP52
Operating Temperature - Maximum
150 Degrees F
Operating Temperature - Minimum
-40 Degrees F
Case Liquid
None
Process Media Temperature - Maximum
150 Degrees F
NEMA Enclosure Rating
5
Process Media Temperature - Minimum
-40 Degrees F

Description

Low Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Center Back, Case Color Black, IP/NEMA Rating IP52, Primary Pressure Range 0 to 200, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Low Pressure Gauge, Liquid-Filled Case No
