Winters Low Pressure Gauge, 0 to 55 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material PLP302 - main

Low Pressure Gauge, 0 to 55 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material

  • Mfr # PLP302

  • Zoro # G1937282

product price:  $44.15
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
PLP302
Zoro #
G1937282
UPC #
628311203172
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Case Diameter
2.625 in
Case Depth
1.9 in
Manufacturer Warranty Length
5 yr
Nominal Dial Size
2 1/2 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Low Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Air Compressors, Air Filters, Regulators and Respirators, Vacuum Applications
Gauge Case Material
Steel
Series
PLP
Lens Material
Polycarbonate
Primary Pressure Range
0 to 55
Primary Scale Units
in wc
IP/NEMA Rating
IP52
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Gauge Secondary Range Values
0 to 70,000
For Use With
Air Compressors, Air Filters, Gas Burners, Respirators, Suction Regulators, Vacuum Ovens, Vacuum Pumps
Case Color
Black
Gauge Primary Range Smallest Graduation
5/1
Smallest Graduation
5 in wc/0.5 in-oz
Calibration Certificate Included
No
Gauge Primary Range Numbered Graduations
10/5
Gauge Special Options
Diaphragm
Case Material
Steel
Socket Material
Brass
Gauge Application
For Natural Gas & Other Gases
Characteristics
Suitable for Corrosive and Non Corrosive Gaseous Media, Natural Gas and Propane Pressure, Air Flow Indication, Leak Detection
Standards
CRN Registered
Connection Type
MNPT
Dial Color
White
Sensor Type
Diaphragm
Primary Scale Minor Graduations
1, 5
Accuracy Grade
ASME B40.100 Grade B
Case Finish
Painted
Secondary Scale Units
oz/in2
Scale Type
Dual
Includes Vent Plug
No
Vibration Resistance
None
Bezel Mounting Type
No Bezel
Process Connection Gender
Male
Dial Face Material
Aluminum
Over-Pressure Limit
30% of Full Scale
Gauge Case Liquid
None
Accuracy Scale
Mid-Scale
Pointer Color
Black
Pressure Range Type
Pressure
Dry Dampening Feature
None
Removable Bezel
No
Pressure Gauge Type
Low Pressure Gauge
Includes Calibration Certificate
No
Pointer Characteristics
Aluminum, Anodized Black
Sensor Material
Phosphor Bronze
Cleaned for Oxygen Service
No
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Compatible Process Media
Gaseous
Primary Scale Numeric Increments
5, 10
Adjustable Pointer
No
Freeze Resistant Movement
No
Includes Mounting Hardware
No
Field Fillable
No
Process Temperature Range
-40 Degrees to 150 Degrees F
Pointer Material
Aluminum
Secondary Pressure Range
0 to 32
Operating Temperature Range
-40 Degrees to 150 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 oz/sq in
Primary Scale Pressure Measurement - Minimum
0 in wc
Secondary Scale Pressure Measurement - Maximum
32 oz/sq in
Primary Scale Pressure Measurement - Maximum
55 in wc
Operating Temperature - Minimum
-40 Degrees F
Case Liquid
None
IP Rating
IP52
Operating Temperature - Maximum
150 Degrees F
Process Media Temperature - Minimum
-40 Degrees F
NEMA Enclosure Rating
5
Compatible with Brand
Universal
Process Media Temperature - Maximum
150 Degrees F

Description

Low Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating IP52, Primary Pressure Range 0 to 55, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Low Pressure Gauge, Liquid-Filled Case No
