EffluentPump, 20ft, 10.5A, 0.5hp, 115VAC

Mfr # 153-0002
Zoro # G0283026

609.99

Free Shipping & Returns

Key Features

Phase - Pumps

Cord Length

20 ft

1/2

Impeller Material

Thermoplastic

Amps

10.5 A

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Details

MFR #: 153-0002
Zoro #: G0283026
UPC #: 053514264574
Country of Origin: United States
Item: Effluent Pump
Phase - Pumps: 1
HP: 1/2
Impeller Material: Thermoplastic
Amps: 10.5 A
Body Material: Cast Iron
Max. Head: 44 ft
Switch Actuation: No Switch Included
Voltage - Pumps: 120VAC
Discharge NPT: 1-1/2"
Handle: yes
GPM of Water @ 30 Ft. of Head: 33
Pump HP: 1/2
Includes: 1-1/2" x 2" PVC Adapter Fitting
Voltage: 115V
Max. Liquid Temp.: 130 Degrees F
Motor RPM: 3450
Top Material: Cast Iron
Phase: Single
Agency Compliance: CSA, UL
Bearing Type: Lower Ball, Upper Sleeve
GPM of Water @ 20 Ft. of Head: 52
Pump RPM: 3450
Shaft Seal Material - Pumps: Carbon, Ceramic
Item - Effluent Pumps: Submersible Effluent Pump
Motor Type: Oil Filled
Hz: 60 Hz
Switch Type: None
GPM of Water @ 25 Ft. of Head: 42
Input Phase AC: 1
Max. Head - Pumps: 44 ft.
Housing Material: Cast iron
Shaft Seal: Carbon/Ceramic
Thermal Protection: Manual
Impeller Material - Pumps: Polypropylene
GPM of Water @ 10 Ft. of Head: 70
GPM of Water @ 15 Ft. of Head: 61
Base Material: Cast Iron
Amps - Pumps: 10.50
GPM of Water @ 5 Ft. of Head: 77
Pump Body Material: Cast Iron
Switch Type - Pumps: No Switch Included
GPM of Water @ 35 Ft. of Head: 22
Duty: Continuous
Discharge: 1 1/2 in FNPT
Alarm Included: No
Discharge Standard: NPT
Discharge Gender: Female
Switch Electrical Connection: No Switch Included
Flow Rate @ 40 Ft. of Head: 11 gpm
Flow Rate @ 10 Ft. of Head: 70 gpm
RPM: 3,450 RPM
Flow Rate @ 15 Ft. of Head: 61 gpm
Rated Voltage: 115V AC
Duty Cycle: Intermittent
Flow Rate @ 20 Ft. of Head: 52 gpm
NEC Cord Designation: SJTW
Liquid Temperature - Maximum: 130 Degrees F
Includes Alarm: No Alarm Included
Feet of Head - Maximum: 44 ft
Flow Rate @ 10 ft of Head: 70 gpm
Horsepower: 1/2 hp
Volute Material: Cast Iron
Frequency: 60 Hz
Rotation Speed - Maximum: 3,450 RPM
For Media Type: Effluent Water
Requires Control Panel: Control Panel Required
Standards: CSA Certified, UL Listed
Motor Housing Material: Cast Iron
Shaft Seal Type: Single Mechanical
Current: 10.5 A
Shaft Seal Material: Carbon/Ceramic
Flow Rate @ 40 ft of Head: 11 gpm
Power Source: Corded Electric
Hazardous Location Class: Not Rated
Flow Rate @ 20 ft of Head: 52 gpm
Impeller Design: Vortex
Power Source - TS Only: Corded Electric
Power Source - old: Corded Electric

Description

Effluent Pump, HP 1/2, Rated Voltage 115V AC, Hz 60 Hz, Phase - Pumps 1, Amps 10.5 A, Body Material Cast Iron, Impeller Material Thermoplastic, Shaft Seal Material - Pumps Carbon, Ceramic, Switch Actuation No Switch Included, Switch Electrical Connection No Switch Included, Flow Rate @ 10 Ft. of Head 70 gpm, Flow Rate @ 15 Ft. of Head 61 gpm, Flow Rate @ 20 Ft. of Head 52 gpm, Flow Rate @ 40 Ft. of Head 11 gpm, Max. Head 44 ft, Min. Sump Pit Dia. 18 in, Minimum Water Depth 18 in
