Primary Sump Pump, 3/10 HP, 2580,115/120 V
- Mfr # 508-0006
- Zoro # G6279135
product price:Â
$
810.00
/ea
Free Shipping & Returns
Key Features
HP
3/10 (Primary); 1/3 (Secondary)
Body Material
Cast Iron (Primary)
Alarm Output
Audible
Switch Actuation
Vertical Float
Flow Rate @ 10 Ft. of Head
34.0 gpm (Primary); 30.0 gpm (Secondary)
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- 508-0006
- Zoro #
- G6279135
- UPC #
- 053514383503
- Country of Origin
- United States
- HP
- 3/10 (Primary); 1/3 (Secondary)
- Body Material
- Cast Iron (Primary)
- Alarm Output
- Audible
- Switch Actuation
- Vertical Float
- Flow Rate @ 10 Ft. of Head
- 34.0 gpm (Primary); 30.0 gpm (Secondary)
- Max. Head
- 19.0 ft (Primary); 22.0 ft (Secondary)
- Shaft Seal Material - Pumps
- Carbon, Ceramic
- Max. Flow (GPH) - Pumps
- 2580
- Item - Sump Pumps
- Sump/Battery Back-Up System
- Alarm Duration
- Manual Reset
- Off Point
- Adjustable
- Max. Head - Pumps
- 19 ft.
- GPM of Water @ 5 Ft. of Head
- 43 (Primary), 39 (Secondary)
- Pump Body Material
- Cast Iron
- Pump HP
- 3/10
- Motor Type
- 1-Phase
- Max. Head (Ft.) - Back-Up
- 22
- GPH of Water @ 5 Ft. of Head
- 2580 (Primary), 2340 (Secondary)
- Outlet
- 1-1/2"
- On Point (In.)
- 7-1/4"
- Discharge NPT
- 1-1/2" M
- Voltage - Pumps
- 120VAC
- Input Phase AC
- 1
- Alarm Included
- Yes
- Agency Compliance
- CSA
- Switch Type - Pumps
- Vertical
- Pump RPM
- 1550
- Base Material
- Thermoplastic
- On Point
- Adjustable
- Off Point (In.)
- 3
- Voltage - Back-Up
- 12VDC
- GPM of Water @ 15 Ft. of Head
- 23' TDH (Primary), 22' TDH (Secondary 12V)
- Amps
- 9.7 A
- GPH of Water @ 10 Ft. of Head
- 2040 (Primary), 1800 (Secondary)
- 12VDC Battery Charger
- 10A
- Alarm
- Audible Alarm on Charger
- Amps - Pumps
- 9.70
- Impeller Material
- Cast Iron (Primary); Thermoplastic (Secondary)
- Alarm Duration - Pumps
- Continuous
- Amps - Back-Up
- 10.00
- GPH of Water @ 15 Ft. of Head
- 1140 (Primary), 1200 (Secondary)
- Motor RPM
- 1550
- Max. Liquid Temp.
- 130 Degrees F
- Hz
- 60 Hz
- Voltage
- 115/120
- Max. Flow (GPH)
- 2580
- Max. Flow (GPH) - Back-Up
- 39
- Switch Type
- Vertical Float
- Duty
- Intermittent
- GPM of Water @ 10 Ft. of Head
- 34 (Primary), 30 (Secondary)
- Housing Material
- Cast iron
- Shaft Seal
- Carbon Ceramic
- Bearing Type
- Sleeve
- Alarm Output - Pumps
- Audible
- Includes
- Battery Box, Battery Charger, Check Valve, Installation Hardware Kit, Monitoring Controller
- Impeller Material - Pumps
- Cast Iron (Primary), Thermoplastic (Secondary)
- Item
- Sump/Battery Back-Up System
- Handle
- Stainless Steel
- Phase
- 1
- Flow Rate @ 5 Ft. of Head
- 43.0 gpm (Primary); 39.0 gpm (Secondary)
- Secondary Pump Impeller Material
- Thermoplastic
- Primary Pump Flow Rate @ 10 Ft. of Head
- 34.0 gpm
- Primary Pump Shaft Seal Material
- Carbon/Ceramic
- RPM
- 1,550 RPM
- Secondary Pump Flow Rate @ 5 Ft. of Head
- 39.0 gpm
- Primary Pump Rated Voltage
- 120V AC
- Primary Pump Impeller Material
- Cast Iron
- Secondary Pump Maximum Head
- 22 ft
- Secondary Pump HP
- 1/3 hp
- Flow Rate @ 15 Ft. of Head
- 19.0 gpm (Primary); 20.0 gpm (Secondary)
- Primary Pump Phase
- Single
- Primary Pump Flow Rate @ 15 Ft. of Head
- 19.0 gpm
- Primary Pump Hz
- 60
- Secondary Pump Flow Rate @ 10 Ft. of Head
- 30.0 gpm
- Discharge Standard
- PVC Glue
- Switch Electrical Connection
- Integral, Piggyback
- Alarm Application
- Indoor
- Secondary Pump Flow Rate @ 15 Ft. of Head
- 20.0 gpm
- Secondary Pump Amps
- 10
- Primary Pump Amps
- 9.7
- Primary Pump RPM
- 1,550
- Primary Pump HP
- 3/10 hp
- Discharge
- 1-1/2 in M PVC Glue
- Primary Pump Maximum Head
- 19 ft
- Primary Pump Flow Rate @ 5 Ft. of Head
- 43.0 gpm
- Primary Pump Duty Cycle
- Intermittent
- Duty Cycle
- Intermittent
- Secondary Pump Rated Voltage
- 12V DC
- Discharge Gender
- Male
- Primary Pump Body Material
- Cast Iron
- Primary Pump Speed
- 1,550 RPM
- Primary Pump Flow Rate @ 10 ft of Head
- 34 gpm
- Alerts Indicated
- Continuous Run, High Control Voltage, High Water, Power Outage, Pump Contactor Failure, Pump End of Lifecycle, Pump Fail to Run, Seal Failure
- Alert Output
- Audio, Visual
- Primary Pump Switch Actuation
- Vertical Float
- Primary Pump Horsepower
- 3/10 hp
- Secondary Pump Flow Rate @ 10 ft of Head
- 30 gpm
- Standards
- CSA
- Primary Pump Frequency
- 60 Hz
- Primary Pump Current
- 9.7 A
- Power Source
- Corded Electric
- Secondary Pump Switch Actuation
- Vertical Float
- Primary Pump Switch Electrical Connection
- Integral
- Secondary Pump Horsepower
- 1/3 hp
- Liquid Temperature - Maximum
- 130 Degrees F
- Series
- Aquanot
- Includes Alarm
- Alarm Included
- Feet of Head - Maximum
- 19.0 ft (Primary); 22.0 ft (Secondary)
- For Media Type
- Clear Water
- Secondary Pump Current
- 10 A
- Power Source - TS Only
- Corded Electric
- Power Source - old
- Corded Electric
Description
Sump/Battery Back-Up System
Dimensions
- Min. Sump Pit Dia.
- 18 in
- Cord Length
- 9 ft
- Max. Diameter Solids
- 1/2 in
- Max. Dia. Solids (In.) - Back-Up
- 1/2"
- Manufacturers Warranty Length
- 3 yr
- Width
- 8-7/8"
- Diameter
- 8" (Secondary), 7-7/8" (Secondary)
- Length
- 10-1/16" (Primary), 7-7/8" (Secondary)
- Cord Length - Pumps
- 9 ft.
- Height
- 10-1/16"
- Width at Widest Point
- 8 7/8 in
- Primary Pump Width at Widest Point
- 8 7/8 in
- Secondary Pump Body Diameter
- 7 7/8 in
- Overall Height
- 10 1/8 in
- Primary Pump Overall Height
- 10 1/8 in
- Body Dia.
- 8 in
- Primary Pump Maximum Solids Diameter
- 1/2 in
- Discharge Dia.
- 1 1/2 in
- Primary Pump Solids Diameter - Maximum
- 1/2 in
- Sump Pit Diameter - Minimum
- 18 in
- Discharge Diameter
- 1 1/2 in
