4" Socket Weld SS Socket Weld Flange Sch 40

  • Mfr # 4381005670

  • Zoro # G1120183

product price:  $156.99
/ea
Free Shipping & Returns

Key Features

Pipe Size - Pipe Fitting
4"
Specific Fitting Shape
Socket Weld Flange
Pipe Fitting Material
Forged 316 Stainless Steel
Fitting Connection Type
Socket Weld
Fitting Schedule/Class
Class 300
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
4381005670
Zoro #
G1120183
UPC #
-
Country of Origin
Viet Nam

Dimensions

Pipe Size - Pipe Fitting
4"
Pipe Size (Fittings)
4"
Outside Dia.
10"
Pipe Size
4"
Nominal Pipe Size
4 in
Overall Length
1 7/8 in
Bolt Hole Diameter
7/8 in
Flange Outside Diameter
10 in
Flange Thickness
1 1/4 in
Bolt Circle Diameter
7 7/8 in
Wire Rope Length
1 7/8 in

Details

Specific Fitting Shape
Socket Weld Flange
Pipe Fitting Material
Forged 316 Stainless Steel
Fitting Connection Type
Socket Weld
Fitting Schedule/Class
Class 300
Basic Pipe Fitting Shape
Flange
Basic Pipe Fitting Material
Metal
Item
Socket Weld Flange
Pipe Fitting Connection Type
Socket Weld
Specific Pipe Fitting Shape
Socket Weld Flange
Max. Pressure
720 psi
Number of Holes
8
Fittings Sub-Category
Flanges
Pipe Fitting Schedule/Class
Class 300
Max. Steam Pressure
300 psi
Standards
ASME A182, ASME B1.20.1, ASME B16.5
Number of Bolt Holes
8
Material Grade
316/316L
Maximum Operating Pressure
720 psi
Class
Class 300
Connection Surface
Raised
Schedule
Sch.40
Type
Forged
Gravity Flow
Pressure
Pipe Connection Type
Socket
Pipe Connection Gender
Female
Finish/Coating
Plain

Description

The ZORO SELECT 4381005670 is a stainless steel socket weld flange rated for operation up to 720 psi. It features a recessed socket to accept pipe ends, which are secured with a fillet weld around the hub. Nominal Pipe Size: 4 in, it offers good alignment.

  • Material: Forged 316 Stainless Steel for strength and corrosion resistance
  • Connection Type: Socket Weld for pipe attachment
  • Pressure Ratings: Max. pressure of 720 psi; Max. steam pressure of 300 psi; Maximum operating pressure of 720 psi
  • Flange Dimensions: Outside diameter 10 in; Thickness 1 1/4 in
  • Bolt Circle Diameter: 7 7/8 in with 8 bolt holes
  • Bolt Hole Diameter: 7/8 in and overall hole count of 8
  • Flange Outside Diameter: 10 in
  • Overall Length: 1 7/8 in
  • Standards: ASTM-SA182; ANSI B16.5
  • Class: 300
  • Nominal Pipe Size: 4 in
  • Fitting Schedule/Class: Class 300
  • Connection Surface: Raised Face

    • Restrictions

    This is a restricted item in the USA. It cannot be used for potable water applications.
