Zoro Select Capacitor-Start Belt Drive Motor, 1/3 HP, 48Z Frame, 115/208-230V AC Voltage, 1,725 Nameplate RPM 1AGG2 - main

Capacitor-Start Belt Drive Motor, 1/3 HP, 48Z Frame, 115/208-230V AC Voltage, 1,725 Nameplate RPM

  • Mfr # 1AGG2

  • Zoro # G3234454

product price:  $318.99
/ea
Free Shipping & Returns

Key Features

Motor Design
Capacitor-Start
Motor Enclosure Design
Open Dripproof
HP
1/3
No. of Speeds
1
RPM Range
1,701-1,800
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
1AGG2
Zoro #
G3234454
UPC #
190735131220
Country of Origin
United States

Dimensions

Shaft Dia.
1/2 in
Resilient Ring Dia.
2 1/4 in
Shaft Length
1 7/8 in
Body Dia.
5 5/8 in
Length Less Shaft
8 5/16 in
Overall Length
10 1/4 in

Details

Item
Belt Drive Motor
Motor Design
Capacitor-Start
Motor Enclosure Design
Open Dripproof
HP
1/3
No. of Speeds
1
RPM Range
1,701-1,800
Nameplate RPM
1,725
Voltage
115/208-230V AC
Frame
48Z
Motor Mounting Type
Cradle Base
Motor Thermal Protection
Auto
Motor Service Factor
1.35
Voltage Compatibility
115/200-230V AC, 115/208-230V AC, 115V AC, 208-230V AC
Phase
Single
Motor Application
HVAC/R
Motor Sub Application
Belt Drive Fan/Blower
Motor Mounting Position
All Angle
Hz
60 Hz
Full Load Amps
5.8/3.1-2.9 A
Motor Bearings
Ball
Standards
CSA Certified, UL Recognized
Mounting Stud Pattern
3-5/8 in x 3-5/8 in
Ring to Ring Center
7 7/8 in
Motor Shaft Rotation
CW/CCW
Motor Frame Material
Steel
Max. Ambient Temp.
104 Degrees F
Duty
Continuous
Frame Material
Rolled steel
Ins. Class
B
Motor Shaft Design
Keyed
Includes
Capacitor
Usable @ 200V
No
Usable @ 208V
Yes
Duty Cycle
Continuous

Description

Fan and Blower Motor, Single Phase, Motor Design Capacitor-Start, 1/3 hp HP, Nameplate RPM 1,725 RPM, No. of Speeds 1, Voltage 115/208-230V AC, 5.8/3.1-2.9 A Full Load Amps, 48Z Frame, Usable @ 208V Usable at 208V, Usable @ 200V Not Usable at 200V, 60 Hz Hz, Motor Service Factor 1.35, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Drip Proof, Motor Mounting Type Cradle Base
