  5. Commercial Pressure Gauge, 0 to 300 psi, 2 in Dial, 1/4 in NPT, Bottom Location
Zoro Select Commercial Pressure Gauge, 0 to 300 psi, 2 in Dial, 1/4 in NPT, Bottom Location 4FML1 - main

Commercial Pressure Gauge, 0 to 300 psi, 2 in Dial, 1/4 in NPT, Bottom Location

  • Mfr # 4FML1

  • Zoro # G0040862

product price:  $16.35
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Application
Test and Measurement
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
4FML1
Zoro #
G0040862
UPC #
190735508442
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 in
Nominal Dial Size
2 in
Nominal Dial Diameter
2 in

Details

Item
Commercial Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Test and Measurement
Gauge Case Material
304 Stainless Steel
Lens Material
Acrylic
Primary Pressure Range
0 to 300
Primary Scale Units
psi
IP/NEMA Rating
Not Rated
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Gauge Application
Corrosion-Resistant Case
Gauge Secondary Range Values
0 to 2000
Smallest Graduation
5 psi
Case Color
Silver
Calibration Certificate Included
No
Gauge Primary Range Smallest Graduation
5
Case Material
304 Stainless Steel
Socket Material
316 Stainless Steel
Wetted Materials
Stainless Steel
Connection Type
MNPT
Freeze Resistant Movement
No
Pressure Gauge Type
Commercial Pressure Gauge
Secondary Scale Units
kPa
Non-Sparking
No
Secondary Pressure Range
0 to 2,000
Vibration Resistance
None
Primary Scale Minor Graduations
5
Field Fillable
No
Cleaned for Oxygen Service
No
Pressure Range Type
Pressure
Accuracy Scale
Mid-Scale
Gauge Case Liquid
None
Includes Vent Plug
No
Dry Dampening Feature
None
Dial Color
White
Sensor Material
316 Stainless Steel
Process Connection Gender
Male
Bezel Material
Crimped Stainless Steel
Includes Calibration Certificate
No
Scale Type
Dual
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F
Removable Bezel
No
Includes Mounting Hardware
No
Maximum Pressure
300
Operating Temperature Range
-40 Degrees to 150 Degrees F
Operating Temperature - Maximum
150 Degrees F
Case Liquid
None
Operating Temperature - Minimum
-40 Degrees F
Primary Scale Pressure Measurement - Maximum
300 psi
Secondary Scale Pressure Measurement - Minimum
0 kPa
Secondary Scale Pressure Measurement - Maximum
2,000 kPa
Primary Scale Pressure Measurement - Minimum
0 psi

Description

Commercial Pressure Gauge, Nominal Dial Size 2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material 304 Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Acrylic, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Silver, IP/NEMA Rating Not Rated, Primary Pressure Range 0 to 300, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Commercial Pressure Gauge
