Zoro Select Commercial Pressure Gauge, 0 to 600 psi, 1 1/2 in Dial, 1/8 in BSPT, Center Back Location 4EFD2 - main

Commercial Pressure Gauge, 0 to 600 psi, 1 1/2 in Dial, 1/8 in BSPT, Center Back Location

  • Mfr # 4EFD2

  • Zoro # G0047442

product price:  $3.49
/ea
Sold in multiples of 3 for $10.47

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Size
1/8 in
Process Connection Type
BSPT
Dial Size (In.)
1 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
4EFD2
Zoro #
G0047442
UPC #
190735504468
Country of Origin
China

Dimensions

Process Connection Size
1/8 in
Dial Size (In.)
1 1/2 in
Nominal Dial Size
1 1/2 in
Nominal Dial Diameter
1 1/2 in

Details

Item
Commercial Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Type
BSPT
Application
Test and Measurement
Gauge Case Material
ABS Plastic
Lens Material
Polycarbonate
Primary Pressure Range
0 to 600
Primary Scale Units
psi
IP/NEMA Rating
Not Rated
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Gauge Primary Range Smallest Graduation
10
Case Color
Black
Calibration Certificate Included
No
Smallest Graduation
10 psi
Gauge Application
General-Purpose Case
Socket Material
Brass
Case Material
ABS Plastic
Wetted Materials
Brass / Bronze
Connection Type
BSPT
Accuracy Scale
Mid-Scale
Cleaned for Oxygen Service
No
Dial Color
White
Includes Calibration Certificate
No
Vibration Resistance
None
Scale Type
Single
Primary Scale Minor Graduations
10
Non-Sparking
No
Removable Bezel
No
Field Fillable
No
Pressure Range Type
Pressure
Includes Mounting Hardware
No
Ambient Operating Temperature Range
-4 Degrees to 158 Degrees F
Freeze Resistant Movement
No
Dry Dampening Feature
None
Gauge Case Liquid
None
Includes Vent Plug
No
Sensor Material
Bronze
Pressure Gauge Type
Commercial Pressure Gauge
Maximum Pressure
600
Operating Temperature Range
-4 Degrees to 158 Degrees F
Operating Temperature - Minimum
-4 Degrees F
Primary Scale Pressure Measurement - Minimum
0 psi
Case Liquid
None
Operating Temperature - Maximum
158 Degrees F
Primary Scale Pressure Measurement - Maximum
600 psi

Description

Commercial Pressure Gauge, Nominal Dial Size 1 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material ABS Plastic, Process Connection Type BSPT, Lens Material Polycarbonate, Process Connection Size 1/8 in, Field Fillable No, Process Connection Location Center Back, Case Color Black, IP/NEMA Rating Not Rated, Primary Pressure Range 0 to 600, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Commercial Pressure Gauge, Liquid-Filled Case No

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
