Gasket Sheet, 1/8 in., White, PTFE

  • Mfr # 24SH-30125
  • Zoro # G0170348

product price:
$
698.99
/ea
Free Shipping & Returns

Key Features

Metal Detectable
No
Material of Construction
Expanded PTFE
Thickness
1/8 in
Temp. Range (F)
-400 Degrees to 599 Degrees F
Length
30 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
24SH-30125
Zoro #
G0170348
UPC #
-
Country of Origin
Austria
Item
Gasket Sheet
Metal Detectable
No
Material of Construction
Expanded PTFE
Temp. Range (F)
-400 Degrees to 599 Degrees F
Type
Sheet
Max. Pressure (PSI)
2,900 psi
Standards
AREVA, BAM, Blow-Out-Test VDI 2200, FDA Compliant, TA-Luft, USP Plastic Class VI, WRC
Color
White
Continuous Max. Temp. (F)
518 Degrees F
Binder Material
None
Market
Industrial
For Piping System
Food and Beverage
FDA Approved
Yes
For Fluid Type
Water
Reinforced
No
For Environment
Food and Beverage
X-Ray Detectable
No
Form
Sheet
Resistance Properties
Chemical-Resistant
Minimum Operating Temperature
-450 Degrees F
Maximum Operating Temperature
600 Degrees F
Gasket Material
ePTFE
System of Measurement
Inch
Maximum Operating Pressure
2,900 psi
Features
Does not get Wider when Compressed, Non-Toxic, Operates with Minimal Creep at Elevated Temperatures, Universally employable Gasket Sheet for all Applications, Used Gaskets can be Removed without Residue

Dimensions

Thickness
1/8 in
Length
30 in
Width
30 in
Overall Width
30 in
Overall Length
30 in

Description

Gasket Sheet, Gasket Material ePTFE, Color White, Backing Type Plain, Binder Material None, Overall Width 30 in, Overall Length 30 in, Thickness 1/8 in, Form Sheet, Minimum Operating Temperature -450 Degrees F, Reinforced No, Maximum Operating Pressure 2,900 psi, Maximum Operating Temperature 600 Degrees F, Metal Detectable No, X-Ray Detectable No, Hardness Not Applicable, Standards AREVA, BAM, Blow-Out-Test VDI 2200, FDA Compliant, TA-Luft, USP Plastic Class VI, WRC
