Zoro Select Plate Caster, 800 lb. Load, Black Wheel P21S-PH040R-16-WB-DL - main

Plate Caster, 800 lb. Load, Black Wheel

  • Mfr # P21S-PH040R-16-WB-DL

  • Zoro # G5554022

product price:  $43.99
/ea

Key Features

Frame Finish
Zinc Plated
Mounting Bolt Dia.
1/2 in
Caster Brake Included
Yes
Includes
Complete Caster with Directional Lock
Core Color
Black
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
P21S-PH040R-16-WB-DL
Zoro #
G5554022
UPC #
-
Country of Origin
China

Dimensions

Mounting Bolt Dia.
1/2 in
Overall Height
5-5/8in
Swivel Radius
3 5/8 in
Wheel Dia.
4 in
Wheel Width
2 in
Mounting Plate Size
4-1/2 in x 6-1/4 in
Mounting Height
5 5/8 in
Outside Slot Spacing - Width
3.375 in
Mounting Plate Thickness
0.236 in
Mounting Plate Width
4 1/2 in
Inside Slot Spacing - Length
4.938 in
Outside Slot Spacing - Length
5.25 in
Mounting Plate Length
6 1/4 in
Inside Slot Spacing - Width
2.438 in
Overall Wheel Width
2 in
For Axle Dia.
1/2 in

Details

Frame Finish
Zinc Plated
Caster Brake Included
Yes
Includes
Complete Caster with Directional Lock
Core Color
Black
Thread Guards
No
Caster Temp. Range Available
Yes
Caster Sub-Type
Swivel
Extended Lead
No
Features
Push/Pull Force Reduction
Non-Marking
Yes
Caster Brake Type
Directional Lock, Side Brake
Caster Frame Material
Steel
Caster Plate Hole Pattern
A
Load Rating
800 lb
Wheel Color
Black
Outside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Number of Wheels
1
Inside Bolt Hole Spacing
2-7/16 in x 4-15/16 in
Application
Dollies, Floor Trucks, Shop Carts, Warehouse Trucks, Waste Disposal Trucks
Item
Swivel Caster With Brake And Directional-Lock
Standards
ANSI ICWM
Replacement Wheel
Mfr. No. P-PH-040x020/050R
Wheel/Tread Hardness Rating
Hard
Load Rating Range
Medium Duty
Swivel Construction
Kingpin
Swivel Lock Type
4-Position Directional Lock
Wheel Core Material
Phenolic
Includes Thread Guards
No
Tread Shape
Standard
Swivel Raceway Type
Double Ball
Wheel Bearing Type
Roller
Number of Mounting Holes
4
Wheel/Tread Material
Phenolic
Wheel/Tread Color
Black
System of Measurement
Inch
Caster Mounting Type
Plate
ESD Conductive
No
Tread Color
Black
Series
P21 Series
Resistant To
High Chemical Resistance To Many Aggressive Substances
Load Capacity
800 lb
Tread
Standard
Load Capacity - Maximum
800 lb
Wheel Bearing Material
Steel
Mounting Hole Type
Slot
Brake Location
Side
Wheel Core Type
Solid
Wheel Hardness Rating
Rockwell 102E
Mounting Plate Shape
Rectangle
Caster Features
Corrosion-Resistant
For Surface Type
Grease, Metal Scrap, Oil, Rubber, Steel, Wood
Operating Temperature - Maximum
250 Degrees F
Operating Temperature Range
-40 Degrees To 250 Degrees F
Operating Temperature - Minimum
-65 Degrees F

Description

Swivel, Plate Caster, Load Rating 800 lb, Swivel Lock Type 4-Position Directional Lock, Wheel Dia. 4 in, Wheel Width 2 in, Wheel/Tread Material Phenolic, Wheel Core Material Phenolic, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Directional Lock, Side Brake, Tread Shape Standard
