Shop ZORO SELECT

Plate Caster, Swivel, 280 lb., Light-Duty

  • Mfr # 426A86

  • Zoro # G1616999

product price:
$
57.99
/ea

Key Features

Wheel Dia.
8 in
Number of Wheels
1
Caster Brake Type
Side Brake
Standards
ANSI, ANSI ICWM
Swivel Radius
5 3/4 in
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
426A86
Zoro #
G1616999
UPC #
-
Country of Origin
China

Dimensions

Wheel Dia.
8 in
Swivel Radius
5 3/4 in
Mounting Bolt Dia.
3/8 in
Overall Height
9-1/2"
Wheel Width
2 in
Mounting Plate Size
4 in x 4 1/2 in
Mounting Height
9 1/2 in
Mounting Plate Thickness
15/64in

Details

Number of Wheels
1
Caster Brake Type
Side Brake
Standards
ANSI, ANSI ICWM
Load Rating
280 lb
Non-Marking
No
Thread Guards
No
Caster Temp. Range Available
Yes
Caster Plate Hole Pattern
B
Wheel Color
Black
Caster Sub-Type
Swivel
Application
Aerospace Tooling, All Purpose Industrial and Commercial Casters, Automotive Assembly Lines, Body Dolly Carts, Chassis Rack Carts, Engine Dollies, Material Carts
Core Color
Silver
Outside Bolt Hole Spacing
2-5/8 in x 3-5/8 in
Caster Frame Material
Steel
Caster Brake Included
Yes
Frame Finish
Zinc Plated
Item
Plate Caster
Inside Bolt Hole Spacing
3 in x 3 in
Extended Lead
No
Swivel Lock Type
No Lock Included
Tread Shape
Standard
Wheel/Tread Material
Rubber
Wheel Core Material
Steel
Includes Thread Guards
No
Swivel Construction
Kingpin
Load Rating Range
0 to 299 lb
Wheel Bearing Type
Ball
Swivel Raceway Type
Double Ball
Number of Mounting Holes
4
Wheel/Tread Hardness Rating
Soft
Wheel/Tread Color
Black
Tread
Centipede
Wheel Hardness Rating
70 Shore A
Load Capacity - Maximum
280 lb
Operating Temperature - Maximum
180 Degrees F
Operating Temperature - Minimum
-40 Degrees F

Description

Swivel, Plate Caster, Load Rating 280 lb, Swivel Lock Type No Lock Included, Wheel Dia. 8 in, Wheel Width 2 in, Wheel/Tread Material Rubber, Wheel Core Material Steel, Non-Marking No, Number of Wheels 1, Caster Brake Type Side Brake, Tread Shape Standard

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
