  6. Plate Caster, Swivel, Polyurethane, 6 1/2"H
Zoro Select Plate Caster, Swivel, Polyurethane, 6 1/2"H P21S-UP050R-14-DL - main

Plate Caster, Swivel, Polyurethane, 6 1/2"H

  • Mfr # P21S-UP050R-14-DL

  • Zoro # G3573891

product price:  $30.69
/ea

Key Features

Frame Finish
Zinc Plated
Swivel Radius
4 1/4 in
Wheel/Tread Material
Polyurethane
Swivel Lock Type
Directional Lock
Features
Floor Protection
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
P21S-UP050R-14-DL
Zoro #
G3573891
UPC #
-
Country of Origin
China

Dimensions

Swivel Radius
4 1/4 in
Wheel Dia.
5 in
Mounting Plate Size
4in x 4-1/2in
Mounting Height
6 1/2 in
Wheel Width
2 in
Overall Height
6-1/2in
Mounting Bolt Dia.
3/8 in
For Axle Dia.
1/2 in
Mounting Plate Thickness
1/4in
Inside Slot Spacing - Length
3 in
Outside Slot Spacing - Length
3.625 in
Outside Slot Spacing - Width
3 in
Overall Wheel Width
2 in
Inside Slot Spacing - Width
2.625 in
Mounting Plate Length
4 in

Details

Frame Finish
Zinc Plated
Wheel/Tread Material
Polyurethane
Swivel Lock Type
Directional Lock
Features
Floor Protection
Swivel Raceway Type
Double Ball
Application
Food Service Racks and Cases, Hotel Equipment, Laundry Trucks, Office Equipment, Stock Carts, Store Fixtures, Utility Carts
Core Color
Gray
Wheel Color
Gray
Caster Brake Type
Directional Lock
Extended Lead
No
Caster Mounting Type
Plate
Wheel/Tread Hardness Rating
Hard
Wheel Core Material
Polypropylene
Thread Guards
No
Wheel Bearing Type
Roller
Item
Swivel Caster with Four Position Swivel Lock
Caster Brake Included
No
Outside Bolt Hole Spacing
2-5/8 in x 3-5/8 in
Caster Plate Hole Pattern
B
System of Measurement
Inch
Standards
DIN EN 12532
Caster Sub-Type
Swivel
Inside Bolt Hole Spacing
3 in x 3 in
Tread Color
Gray
Caster Frame Material
Steel
Includes
Directional Lock
Non-Marking
Yes
Replacement Wheel
Mfr. No. P-UP-050x020/050R
Number of Wheels
1
Includes Thread Guards
No
Tread
Standard
Caster Temp. Range Available
Yes
Load Rating
750 lb
Tread Shape
Standard
Swivel Construction
Kingpin
Number of Mounting Holes
4
Load Rating Range
Light-Medium Duty
Wheel/Tread Color
Gray
ESD Conductive
No
Series
P21 Series
Load Capacity
750 lb
Resistant To
High Chemical Resistance To Many Aggressive Substances
Compatible With
P-UP-050X020/050R
Load Capacity - Maximum
750 lb
Wheel Hardness Rating
55 Shore D
Mounting Plate Shape
Rectangle
Wheel Core Type
Solid
Caster Features
Corrosion-Resistant, Debris-Resistant, Maintenance Free, Quiet-Roll
Mounting Hole Type
Slot
Wheel Bearing Material
Steel
For Surface Type
Asphalt, Ceramic, Grease, Oil, Rubber, Steel, Tile, Vinyl, Wood
Operating Temperature - Minimum
-15 Degrees F
Operating Temperature Range
-15 Degrees To 160 Degrees F
Operating Temperature - Maximum
180 Degrees F

Description

Swivel, Plate Caster, Load Rating 750 lb, Swivel Lock Type Directional Lock, Wheel Dia. 5 in, Wheel Width 2 in, Wheel/Tread Material Polyurethane, Wheel Core Material Polyolefin, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Directional Lock, Tread Shape Standard
